Comchip Technology
- Comchip Technology Corporation leads in the design and manufacture of SMD discrete semiconductors. With innovative research and patented manufacturing capabilities, Comchip offers bridge rectifiers, fast efficient rectifiers, switching diodes, Zener diodes, Schottky diodes, TVS and ESD surge protectors. We have the right diode for your application. Comchip Technology is the first manufacturer to standardize DFN/flat chip packaging that are RoHS compliant and zero Tin-Whisker potential by using gold termination. DFN packages are available in SOD-323F (1005), SOD-523F (0603), SOD-723F (0503), SOD-923F (0402) and 0201 sizes.
Comchip products are suitable for vast array of applications including lighting, automotive, industrial computers, TFT-LCD panels, network/telecom, medical, portable and consumer electronics, as well as high reliability applications that can benefit from the zero Tin-Whisker potential.. To ensure superior quality and reliability, Comchip’s quality control process and factory are TS16949, ISO9001, and ISO14001 certified. As an added layer of security, Comchip’s bridge rectifier and TVS have passed UL testing for safety device application. Many Comchip diodes meet the automotive stress test requirements AEC-Q101 and are well suited for automotive as well as high reliability application.
Part Number
Manufacturer
Description
Unit Price
In Stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 5V (Max)
Voltage - Breakdown (Min) : 5.4V
Voltage - Clamping (Max) @ Ipp : 25V
Current - Peak Pulse (10/1000µs) : 3A (8/20µs)
Power - Peak Pulse : 75W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 0.6pF @ 1MHz
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0603 (1608 Metric)
Supplier Device Package : 0603/SOD-523F
0
58829 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 5V (Max)
Voltage - Breakdown (Min) : 5.6V
Voltage - Clamping (Max) @ Ipp : 12V
Current - Peak Pulse (10/1000µs) : 11A (8/20µs)
Power - Peak Pulse : -
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 24pF @ 1MHz
Operating Temperature : -40°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0603 (1608 Metric)
Supplier Device Package : 0603C/SOD-523F
0
11744 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 5V (Max)
Voltage - Breakdown (Min) : 5.4V
Voltage - Clamping (Max) @ Ipp : 20V
Current - Peak Pulse (10/1000µs) : 3A (8/20µs)
Power - Peak Pulse : 60W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 0.6pF @ 1MHz
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0603 (1608 Metric)
Supplier Device Package : 0603C/SOD-523F
0
63890 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 12V
Voltage - Breakdown (Min) : 13V
Voltage - Clamping (Max) @ Ipp : 25V
Current - Peak Pulse (10/1000µs) : 1A (8/20µs)
Power - Peak Pulse : 25W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 12pF @ 1MHz
Operating Temperature : -
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603/SOD-523F
0
140367 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 24V
Voltage - Breakdown (Min) : 25V
Voltage - Clamping (Max) @ Ipp : 47V
Current - Peak Pulse (10/1000µs) : 1A (8/20µs)
Power - Peak Pulse : 47W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 10pF @ 1MHz
Operating Temperature : -
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603/SOD-523F
0
61211 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 5V
Voltage - Breakdown (Min) : 5.1V
Voltage - Clamping (Max) @ Ipp : 15V
Current - Peak Pulse (10/1000µs) : 5A (8/20µs)
Power - Peak Pulse : 75W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 15pF @ 1MHz
Operating Temperature : -
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603/SOD-523F
0
25232 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 5V (Max)
Voltage - Breakdown (Min) : 5.5V
Voltage - Clamping (Max) @ Ipp : 16V
Current - Peak Pulse (10/1000µs) : 8A (8/20µs)
Power - Peak Pulse : 128W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 15pF @ 1MHz
Operating Temperature : -40°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0603 (1608 Metric)
Supplier Device Package : 0603/SOD-523F
0
8799 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 5V (Max)
Voltage - Breakdown (Min) : 5.6V
Voltage - Clamping (Max) @ Ipp : 13V
Current - Peak Pulse (10/1000µs) : 12A (8/20µs)
Power - Peak Pulse : -
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 20pF @ 1MHz
Operating Temperature : -40°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : SC-79, SOD-523
Supplier Device Package : 0603/SOD-523F
0
76546 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 4
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 3.3V (Max)
Voltage - Breakdown (Min) : -
Voltage - Clamping (Max) @ Ipp : 8V
Current - Peak Pulse (10/1000µs) : 5A (8/20µs)
Power - Peak Pulse : 40W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 5-TSSOP, SC-70-5, SOT-353
Supplier Device Package : SOT-353
0
183050 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 4
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 5V
Voltage - Breakdown (Min) : 6.1V
Voltage - Clamping (Max) @ Ipp : 10V
Current - Peak Pulse (10/1000µs) : 8A (8/20µs)
Power - Peak Pulse : 80W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : -
Operating Temperature : -
Mounting Type : Surface Mount
Package / Case : 5-TSSOP, SC-70-5, SOT-353
Supplier Device Package : SOT-353
0
127702 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 3.3V (Max)
Voltage - Breakdown (Min) : 5.7V
Voltage - Clamping (Max) @ Ipp : 10.6V
Current - Peak Pulse (10/1000µs) : 6.5A (8/20µs)
Power - Peak Pulse : 70W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 35pF @ 1MHz
Operating Temperature : -40°C ~ 125°C (TA)
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201/DFN0603
0
15839 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 5V (Max)
Voltage - Breakdown (Min) : 5.5V
Voltage - Clamping (Max) @ Ipp : 15V
Current - Peak Pulse (10/1000µs) : 2A (8/20µs)
Power - Peak Pulse : 30W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 6pF @ 1MHz
Operating Temperature : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201/DFN0603
0
26500 in stock
