Comchip Technology
- Comchip Technology Corporation leads in the design and manufacture of SMD discrete semiconductors. With innovative research and patented manufacturing capabilities, Comchip offers bridge rectifiers, fast efficient rectifiers, switching diodes, Zener diodes, Schottky diodes, TVS and ESD surge protectors. We have the right diode for your application. Comchip Technology is the first manufacturer to standardize DFN/flat chip packaging that are RoHS compliant and zero Tin-Whisker potential by using gold termination. DFN packages are available in SOD-323F (1005), SOD-523F (0603), SOD-723F (0503), SOD-923F (0402) and 0201 sizes.
Comchip products are suitable for vast array of applications including lighting, automotive, industrial computers, TFT-LCD panels, network/telecom, medical, portable and consumer electronics, as well as high reliability applications that can benefit from the zero Tin-Whisker potential.. To ensure superior quality and reliability, Comchip’s quality control process and factory are TS16949, ISO9001, and ISO14001 certified. As an added layer of security, Comchip’s bridge rectifier and TVS have passed UL testing for safety device application. Many Comchip diodes meet the automotive stress test requirements AEC-Q101 and are well suited for automotive as well as high reliability application.
Part Number
Manufacturer
Description
Unit Price
In Stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) : 100mA
Voltage - Forward (Vf) (Max) @ If : 550mV @ 100mA
Speed : Small Signal =
-
30µA @ 10V
6pF @ 10V, 1MHz
Surface Mount
1005 (2512 Metric)
1005/SOD-323F
125°C (Max)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 30µA @ 10V
Capacitance @ Vr, F : 6pF @ 10V, 1MHz
Mounting Type : Surface Mount
Package / Case : 1005 (2512 Metric)
Supplier Device Package : 1005/SOD-323F
Operating Temperature - Junction : 125°C (Max)
0
16411 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 100V
Current - Average Rectified (Io) : 300mA
Voltage - Forward (Vf) (Max) @ If : 820mV @ 300mA
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 50µA @ 100V
Capacitance @ Vr, F : 25pF @ 1V, 1MHz
Mounting Type : Surface Mount
Package / Case : 1005 (2512 Metric)
Supplier Device Package : 1005/SOD-323F
Operating Temperature - Junction : -40°C ~ 150°C
0
1390 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 20V
Current - Average Rectified (Io) : 500mA
Voltage - Forward (Vf) (Max) @ If : 470mV @ 500mA
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 100µA @ 20V
Capacitance @ Vr, F : 100pF @ 0V, 1MHz
Mounting Type : Surface Mount
Package / Case : 1005 (2512 Metric)
Supplier Device Package : 1005/SOD-323F
Operating Temperature - Junction : 125°C (Max)
0
3017 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Single Phase
Technology : Schottky
Voltage - Peak Reverse (Max) : 100V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 750mV @ 1A
Current - Reverse Leakage @ Vr : 500µA @ 100V
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-269AA, 4-BESOP
Supplier Device Package : Mini-Dip (TO-269AA)
0
21379 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Single Phase
Technology : Schottky
Voltage - Peak Reverse (Max) : 40V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 440mV @ 1A
Current - Reverse Leakage @ Vr : 500µA @ 40V
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-269AA, 4-BESOP
Supplier Device Package : Mini-Dip (TO-269AA)
0
4789 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Single Phase
Technology : Schottky
Voltage - Peak Reverse (Max) : 60V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 625mV @ 1A
Current - Reverse Leakage @ Vr : 500µA @ 60V
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-269AA, 4-BESOP
Supplier Device Package : Mini-Dip (TO-269AA)
0
2738 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Single Phase
Technology : Schottky
Voltage - Peak Reverse (Max) : 100V
Current - Average Rectified (Io) : 2A
Voltage - Forward (Vf) (Max) @ If : 850mV @ 1A
Current - Reverse Leakage @ Vr : 500µA @ 100V
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-269AA, 4-BESOP
Supplier Device Package : Mini-Dip (TO-269AA)
0
45340 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Single Phase
Technology : Schottky
Voltage - Peak Reverse (Max) : 40V
Current - Average Rectified (Io) : 2A
Voltage - Forward (Vf) (Max) @ If : 500mV @ 1A
Current - Reverse Leakage @ Vr : 500µA @ 40V
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-269AA, 4-BESOP
Supplier Device Package : Mini-Dip (TO-269AA)
0
39129 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Single Phase
Technology : Schottky
Voltage - Peak Reverse (Max) : 60V
Current - Average Rectified (Io) : 2A
Voltage - Forward (Vf) (Max) @ If : 700mV @ 2A
Current - Reverse Leakage @ Vr : 500µA @ 60V
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-269AA, 4-BESOP
Supplier Device Package : Mini-Dip (TO-269AA)
0
5469 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Single Phase
Technology : Schottky
Voltage - Peak Reverse (Max) : 100V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 850mV @ 1A
Current - Reverse Leakage @ Vr : 500µA @ 100V
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-269AA, 4-BESOP
Supplier Device Package : MBS
0
7870 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Single Phase
Technology : Schottky
Voltage - Peak Reverse (Max) : 40V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 550mV @ 1A
Current - Reverse Leakage @ Vr : 500µA @ 40V
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-269AA, 4-BESOP
Supplier Device Package : MBS
0
31775 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Single Phase
Technology : Schottky
Voltage - Peak Reverse (Max) : 60V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 650mV @ 1A
Current - Reverse Leakage @ Vr : 500µA @ 60V
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-269AA, 4-BESOP
Supplier Device Package : MBS
0
163141 in stock
