Comchip Technology
- Comchip Technology Corporation leads in the design and manufacture of SMD discrete semiconductors. With innovative research and patented manufacturing capabilities, Comchip offers bridge rectifiers, fast efficient rectifiers, switching diodes, Zener diodes, Schottky diodes, TVS and ESD surge protectors. We have the right diode for your application. Comchip Technology is the first manufacturer to standardize DFN/flat chip packaging that are RoHS compliant and zero Tin-Whisker potential by using gold termination. DFN packages are available in SOD-323F (1005), SOD-523F (0603), SOD-723F (0503), SOD-923F (0402) and 0201 sizes.
Comchip products are suitable for vast array of applications including lighting, automotive, industrial computers, TFT-LCD panels, network/telecom, medical, portable and consumer electronics, as well as high reliability applications that can benefit from the zero Tin-Whisker potential.. To ensure superior quality and reliability, Comchip’s quality control process and factory are TS16949, ISO9001, and ISO14001 certified. As an added layer of security, Comchip’s bridge rectifier and TVS have passed UL testing for safety device application. Many Comchip diodes meet the automotive stress test requirements AEC-Q101 and are well suited for automotive as well as high reliability application.
Part Number
Manufacturer
Description
Unit Price
In Stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 60V
Current - Average Rectified (Io) : 3A
Voltage - Forward (Vf) (Max) @ If : 700mV @ 3A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 60V
Capacitance @ Vr, F : 250pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : -50°C ~ 150°C
0
5235 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Tape & Reel (TR)
Alternate Packaging
Series : -
Part Status : Obsolete
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 80V
Current - Average Rectified (Io) : 3A
Voltage - Forward (Vf) (Max) @ If : 850mV @ 3A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 80V
Capacitance @ Vr, F : -
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : 125°C (Max)
0
100 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 100V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 850mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 100V
Capacitance @ Vr, F : -
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : 125°C (Max)
0
18671 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 100V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 810mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 100V
Capacitance @ Vr, F : 380pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : -50°C ~ 150°C
0
20870 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 150V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 870mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 150V
Capacitance @ Vr, F : 380pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : -50°C ~ 175°C
0
2481 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 200V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 900mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 150V
Capacitance @ Vr, F : 380pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : -50°C ~ 175°C
0
2447 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 20V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 500mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 20V
Capacitance @ Vr, F : 380pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : -50°C ~ 175°C
0
1244 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 550mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 40V
Capacitance @ Vr, F : -
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : -40°C ~ 125°C
0
111075 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 550mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 40V
Capacitance @ Vr, F : 380pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : -50°C ~ 150°C
0
11310 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 60V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 750mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 60V
Capacitance @ Vr, F : -
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : -40°C ~ 125°C
0
53629 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 60V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 750mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 500µA @ 60V
Capacitance @ Vr, F : 380pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AB, SMC
Supplier Device Package : DO-214AB (SMC)
Operating Temperature - Junction : -50°C ~ 150°C
0
1755 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Tube
Series : -
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 1200V
Current - Average Rectified (Io) : 6.2A (DC)
Voltage - Forward (Vf) (Max) @ If : 1.7V @ 2A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 100µA @ 1200V
Capacitance @ Vr, F : 136pF @ 0V, 1MHz
Mounting Type : Surface Mount
Package / Case : TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package : TO-263 (D2Pak)
Operating Temperature - Junction : -55°C ~ 175°C
0
450 in stock
