Pulse Electronics Corporation
- Pulse Electronics is the electronic components partner that helps customers build the next great product by providing the needed technical solutions. Pulse has a long operating history of innovation in magnetics, antennas and connectors, as well as the ability to ramp quickly into high-quality, high-volume production. The Company serves the wireless and wireline communications, power management, military/aerospace and automotive industries. Previously, the holding and operating companies were known as Technitrol, Inc. and Pulse Engineering, respectively. Pulse is a participating member of IEEE, ATIS, ETSI, HDMI, the DSL Forum, CommNexus, and MoCA.
Part Number
Manufacturer
Description
Unit Price
In Stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Cut Tape (CT)
Series : -
Part Status : Active
Frequency Group : UHF (300 MHz ~ 1 GHz)
Frequency (Center/Band) : 881MHz
Frequency Range : 869MHz ~ 894MHz
Antenna Type : Helical
Number of Bands : 1
VSWR : -
Return Loss : -9dB
Gain : 0dBi
Power - Max : -
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.098" (2.50mm)
Applications : -
0
607 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Cut Tape (CT)
Series : -
Part Status : Active
Frequency Group : UHF (300 MHz ~ 1 GHz)
Frequency (Center/Band) : 850MHz
Frequency Range : 869MHz ~ 894MHz
Antenna Type : Helical
Number of Bands : 1
VSWR : -
Return Loss : -9dB
Gain : 0dBi
Power - Max : -
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.315" (8.00mm)
Applications : GSM
0
3530 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Tray
Series : -
Part Status : Active
Frequency Group : UHF (300 MHz ~ 1 GHz)
Frequency (Center/Band) : 315MHz
Frequency Range : -
Antenna Type : Helical
Number of Bands : 1
VSWR : -
Return Loss : -10dB
Gain : -5dBi
Power - Max : -
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.276" (7.00mm)
Applications : -
0
1499 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Tray
Series : -
Part Status : Active
Frequency Group : UHF (300 MHz ~ 1 GHz)
Frequency (Center/Band) : 433MHz
Frequency Range : 433MHz ~ 435MHz
Antenna Type : Helical
Number of Bands : 1
VSWR : -
Return Loss : -15dB
Gain : -2.9dBi
Power - Max : -
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Through Hole
Height (Max) : 0.276" (7.00mm)
Applications : -
0
5922 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Tray
Series : -
Part Status : Active
Frequency Group : UHF (1 GHz ~ 2 GHz)
Frequency (Center/Band) : 1.575GHz
Frequency Range : -
Antenna Type : Ceramic Patch
Number of Bands : 1
VSWR : 1.6
Return Loss : -
Gain : -1.5dBic
Power - Max : -
Features : -
Termination : Pin
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.157" (4.00mm)
Applications : GPS
0
2197 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Tray
Series : -
Part Status : Active
Frequency Group : UHF (1 GHz ~ 2 GHz)
Frequency (Center/Band) : 1.575GHz, 1.602GHz
Frequency Range : 1.575GHz, 1.598GHz ~ 1.606GHz
Antenna Type : Ceramic Patch
Number of Bands : 2
VSWR : 1.4, 2.3
Return Loss : -
Gain : -2dBi
Power - Max : -
Features : -
Termination : Pin
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : 0.218" (5.53mm)
Applications : GLONASS, GPS
0
1014 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : -
Series : Patch Antenna
Part Status : Active
Frequency Group : UHF (1 GHz ~ 2 GHz)
Frequency (Center/Band) : 1.621GHz
Frequency Range : 1.617GHz ~ 1.625GHz
Antenna Type : Ceramic Patch
Number of Bands : 1
VSWR : -
Return Loss : -15dB
Gain : 4dBi
Power - Max : -
Features : -
Termination : Pin
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : 0.157" (4.00mm)
Applications : General Purpose
0
100 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : -
Series : Ceramic Patch Antenna
Part Status : Active
Frequency Group : UHF (2 GHz ~ 3 GHz)
Frequency (Center/Band) : 2.45GHz
Frequency Range : 2.4GHz ~ 2.5GHz
Antenna Type : Ceramic Patch
Number of Bands : 1
VSWR : -
Return Loss : -7dB
Gain : 6.5dBi
Power - Max : -
Features : -
Termination : Pin
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : 0.157" (4.00mm)
Applications : Bluetooth, Wi-Fi
0
400 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : -
Series : Ceramic Patch Antenna
Part Status : Active
Frequency Group : UHF (2 GHz ~ 3 GHz)
Frequency (Center/Band) : 2.45GHz
Frequency Range : 2.4GHz ~ 2.5GHz
Antenna Type : Ceramic Patch
Number of Bands : 1
VSWR : -
Return Loss : -4dB
Gain : 6dBi
Power - Max : 5W
Features : -
Termination : Pin
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : 0.157" (4.00mm)
Applications : Bluetooth, Wi-Fi
0
600 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Series : -
Part Status : Active
Type : Antenna
Frequency : 2.4GHz
For Use With/Related Products : W3300
Supplied Contents : Board(s)
0
9 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Bulk
Series : -
Part Status : Active
Frequency Group : UHF (300 MHz ~ 1 GHz)
Frequency (Center/Band) : 892MHz
Frequency Range : 863MHz ~ 928MHz
Antenna Type : PCB Trace
Number of Bands : 2
VSWR : -
Return Loss : -8dB
Gain : 0.8dBi
Power - Max : 2W
Features : -
Termination : Connector, U.FL
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : 0.044" (1.13mm)
Applications : ISM
0
524 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Bulk
Series : -
Part Status : Active
Frequency Group : UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz)
Frequency (Center/Band) : 2.4GHz, 5.4GHz
Frequency Range : 2.4GHz ~ 2.5GHz, 4.9GHz ~ 5.85GHz
Antenna Type : PCB Trace
Number of Bands : 2
VSWR : 2
Return Loss : -
Gain : 5dBi
Power - Max : 2W
Features : -
Termination : Connector, IPEX MHF
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : -
Applications : Bluetooth, WLAN, Zigbee™
0
302 in stock
