Comchip Technology
- Comchip Technology Corporation leads in the design and manufacture of SMD discrete semiconductors. With innovative research and patented manufacturing capabilities, Comchip offers bridge rectifiers, fast efficient rectifiers, switching diodes, Zener diodes, Schottky diodes, TVS and ESD surge protectors. We have the right diode for your application. Comchip Technology is the first manufacturer to standardize DFN/flat chip packaging that are RoHS compliant and zero Tin-Whisker potential by using gold termination. DFN packages are available in SOD-323F (1005), SOD-523F (0603), SOD-723F (0503), SOD-923F (0402) and 0201 sizes.
Comchip products are suitable for vast array of applications including lighting, automotive, industrial computers, TFT-LCD panels, network/telecom, medical, portable and consumer electronics, as well as high reliability applications that can benefit from the zero Tin-Whisker potential.. To ensure superior quality and reliability, Comchip’s quality control process and factory are TS16949, ISO9001, and ISO14001 certified. As an added layer of security, Comchip’s bridge rectifier and TVS have passed UL testing for safety device application. Many Comchip diodes meet the automotive stress test requirements AEC-Q101 and are well suited for automotive as well as high reliability application.
Part Number
Manufacturer
Description
Unit Price
In Stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 30V
Current - Average Rectified (Io) : 200mA
Voltage - Forward (Vf) (Max) @ If : 500mV @ 200mA
Speed : Small Signal =
-
30µA @ 30V
9pF @ 10V, 1MHz
Surface Mount
2-SMD, No Lead
0603C/SOD-523F
125°C (Max)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 30µA @ 30V
Capacitance @ Vr, F : 9pF @ 10V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603C/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
101631 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 30V
Current - Average Rectified (Io) : 200mA
Voltage - Forward (Vf) (Max) @ If : 500mV @ 200mA
Speed : Small Signal =
-
30µA @ 30V
9pF @ 10V, 1MHz
Surface Mount
2-SMD, No Lead
0603C/SOD-523F
125°C (Max)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 30µA @ 30V
Capacitance @ Vr, F : 9pF @ 10V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603C/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
32000 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 30V
Current - Average Rectified (Io) : 200mA
Voltage - Forward (Vf) (Max) @ If : 600mV @ 200mA
Speed : Small Signal =
-
1µA @ 10V
-
Surface Mount
2-SMD, No Lead
0603C/SOD-523F
125°C (Max)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 1µA @ 10V
Capacitance @ Vr, F : -
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603C/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
3695 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) : 200mA
Voltage - Forward (Vf) (Max) @ If : 550mV @ 200mA
Speed : Small Signal =
-
10µA @ 30V
9pF @ 10V, 1MHz
Surface Mount
2-SMD, No Lead
0603C/SOD-523F
125°C (Max)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 10µA @ 30V
Capacitance @ Vr, F : 9pF @ 10V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603C/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
255338 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 45V
Current - Average Rectified (Io) : 200mA
Voltage - Forward (Vf) (Max) @ If : 550mV @ 200mA
Speed : Small Signal =
-
1µA @ 10V
9pF @ 10V, 1MHz
Surface Mount
2-SMD, No Lead
0603C/SOD-523F
-40°C ~ 125°C
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 1µA @ 10V
Capacitance @ Vr, F : 9pF @ 10V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603C/SOD-523F
Operating Temperature - Junction : -40°C ~ 125°C
0
200025 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Digi-Reel®
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 45V
Current - Average Rectified (Io) : 200mA
Voltage - Forward (Vf) (Max) @ If : 550mV @ 200mA
Speed : Small Signal =
-
1µA @ 10V
9pF @ 10V, 1MHz
Surface Mount
2-SMD, No Lead
0603C/SOD-523F
-40°C ~ 125°C
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 1µA @ 10V
Capacitance @ Vr, F : 9pF @ 10V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603C/SOD-523F
Operating Temperature - Junction : -40°C ~ 125°C
0
4000 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 20V
Current - Average Rectified (Io) : 500mA
Voltage - Forward (Vf) (Max) @ If : 470mV @ 500mA
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 100µA @ 20V
Capacitance @ Vr, F : 100pF @ 0V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
275082 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 20V
Current - Average Rectified (Io) : 500mA
Voltage - Forward (Vf) (Max) @ If : 470mV @ 500mA
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 100µA @ 20V
Capacitance @ Vr, F : 100pF @ 0V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
8000 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 20V
Current - Average Rectified (Io) : 500mA
Voltage - Forward (Vf) (Max) @ If : 470mV @ 500mA
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 100µA @ 20V
Capacitance @ Vr, F : 100pF @ 0V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
106833 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 20V
Current - Average Rectified (Io) : 500mA
Voltage - Forward (Vf) (Max) @ If : 470mV @ 500mA
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 100µA @ 20V
Capacitance @ Vr, F : 100pF @ 0V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
4000 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) : 30mA
Voltage - Forward (Vf) (Max) @ If : 370mV @ 1mA
Speed : Small Signal =
-
1µA @ 40V
1.5pF @ 1V, 1MHz
Surface Mount
2-SMD, No Lead
0603/SOD-523F
125°C (Max)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 1µA @ 40V
Capacitance @ Vr, F : 1.5pF @ 1V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
4000 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) : 100mA
Voltage - Forward (Vf) (Max) @ If : 550mV @ 100mA
Speed : Small Signal =
-
30µA @ 10V
6pF @ 10V, 1MHz
Surface Mount
2-SMD, No Lead
0603/SOD-523F
125°C (Max)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 30µA @ 10V
Capacitance @ Vr, F : 6pF @ 10V, 1MHz
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead
Supplier Device Package : 0603/SOD-523F
Operating Temperature - Junction : 125°C (Max)
0
12345 in stock
