Central Semiconductor
- Since 1974, Central Semiconductor has manufactured innovative discrete semiconductors used in electronic products worldwide. Devices currently include standard and custom small signal transistors, bipolar power transistors, MOSFETs, diodes, rectifiers, protection devices, current limiting diodes, bridge rectifiers, thyristors, and silicon carbide devices. Central’s devices are available in industry standard surface mount and through-hole packages, bare die, TLMs (Tiny Leadless Modules™), and MDMs (Multi Discrete Modules™). Central has earned a reputation as a manufacturer of the highest quality products consistently delivered on-time, and a provider of exceptional value-added services.
Part Number
Manufacturer
Description
Unit Price
In Stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 PNP (Quad)
Current - Collector (Ic) (Max) : -
Voltage - Collector Emitter Breakdown (Max) : 40V
Vce Saturation (Max) @ Ib, Ic : -
Current - Collector Cutoff (Max) : 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : -
Power - Max : 3W
Frequency - Transition : 150MHz
Operating Temperature : -
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
2025 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 PNP (Quad)
Current - Collector (Ic) (Max) : 50mA
Voltage - Collector Emitter Breakdown (Max) : 40V
Vce Saturation (Max) @ Ib, Ic : 250mV @ 100µA, 1mA
Current - Collector Cutoff (Max) : 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 125 @ 10mA, 5V
Power - Max : 500mW
Frequency - Transition : 60MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
13 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 PNP (Quad)
Current - Collector (Ic) (Max) : 50mA
Voltage - Collector Emitter Breakdown (Max) : 60V
Vce Saturation (Max) @ Ib, Ic : 250mV @ 100µA, 1mA
Current - Collector Cutoff (Max) : 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 250 @ 10mA, 5V
Power - Max : 500mW
Frequency - Transition : 60MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
2800 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 NPN (Quad)
Current - Collector (Ic) (Max) : 200mA
Voltage - Collector Emitter Breakdown (Max) : 40V
Vce Saturation (Max) @ Ib, Ic : 200mV @ 1mA, 10mA
Current - Collector Cutoff (Max) : 50nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 75 @ 10mA, 1V
Power - Max : 500mW
Frequency - Transition : 250MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
804 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 PNP (Quad)
Current - Collector (Ic) (Max) : 200mA
Voltage - Collector Emitter Breakdown (Max) : 40V
Vce Saturation (Max) @ Ib, Ic : 250mV @ 1mA, 10mA
Current - Collector Cutoff (Max) : 50nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 75 @ 10mA, 1V
Power - Max : 500mW
Frequency - Transition : 200MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
31 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 2 NPN, 2 PNP
Current - Collector (Ic) (Max) : 500mA
Voltage - Collector Emitter Breakdown (Max) : 30V
Vce Saturation (Max) @ Ib, Ic : 1.4V @ 30mA, 300mA
Current - Collector Cutoff (Max) : 30nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 30 @ 300mA, 10V
Power - Max : 650mW
Frequency - Transition : 200MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
84 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 2 NPN, 2 PNP
Current - Collector (Ic) (Max) : -
Voltage - Collector Emitter Breakdown (Max) : 45V
Vce Saturation (Max) @ Ib, Ic : -
Current - Collector Cutoff (Max) : 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : -
Power - Max : 3W
Frequency - Transition : 50MHz
Operating Temperature : -
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
33675 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 2 NPN, 2 PNP
Current - Collector (Ic) (Max) : 500mA
Voltage - Collector Emitter Breakdown (Max) : 30V
Vce Saturation (Max) @ Ib, Ic : 1.4V @ 30mA, 300mA
Current - Collector Cutoff (Max) : 30nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 30 @ 300mA, 10V
Power - Max : 650mW
Frequency - Transition : 200MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
279 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 2 NPN, 2 PNP
Current - Collector (Ic) (Max) : 200mA
Voltage - Collector Emitter Breakdown (Max) : 40V
Vce Saturation (Max) @ Ib, Ic : 250mV @ 1mA, 10mA
Current - Collector Cutoff (Max) : 50nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 70 @ 10mA, 1V
Power - Max : 500mW
Frequency - Transition : 200MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
265 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 NPN (Quad)
Current - Collector (Ic) (Max) : 500mA
Voltage - Collector Emitter Breakdown (Max) : 250V
Vce Saturation (Max) @ Ib, Ic : 500mV @ 2mA, 20mA
Current - Collector Cutoff (Max) : 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 40 @ 30mA, 10V
Power - Max : 1.25W
Frequency - Transition : 50MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
4 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 2 NPN, 2 PNP
Current - Collector (Ic) (Max) : 500mA
Voltage - Collector Emitter Breakdown (Max) : 250V
Vce Saturation (Max) @ Ib, Ic : 700mV @ 2mA, 20mA
Current - Collector Cutoff (Max) : 250nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 25 @ 30mA, 10V
Power - Max : 750mW
Frequency - Transition : 50MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
7200 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 PNP (Quad)
Current - Collector (Ic) (Max) : 500mA
Voltage - Collector Emitter Breakdown (Max) : 250V
Vce Saturation (Max) @ Ib, Ic : 500mV @ 2mA, 20mA
Current - Collector Cutoff (Max) : 250nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 25 @ 30mA, 10V
Power - Max : 750mW
Frequency - Transition : 50MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 14-DIP (0.300", 7.62mm)
Supplier Device Package : TO-116
0
236 in stock
