API Delevan
- API Delevan designs, manufactures, and markets an extensive line of quality inductors, chokes, and coils to satisfy various electrical filtering requirements. The Group concentrates on producing high performance inductive devices to meet stringent government and customer specifications relating to high product quality and reliability.
Part Number
Manufacturer
Description
Unit Price
In Stock
SDS680R-332M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 3.3µH
Tolerance : ±20%
Current Rating : 1.6A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 55 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 120MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 3.3µH
Tolerance : ±20%
Current Rating : 1.6A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 55 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 120MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
0
9621 in stock
SDS680R-333M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 33µH
Tolerance : ±20%
Current Rating : 600mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 190 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 20MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 33µH
Tolerance : ±20%
Current Rating : 600mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 190 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 20MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
0
1970 in stock
SDS680R-472M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 4.7µH
Tolerance : ±20%
Current Rating : 1.4A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 60 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 105MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 4.7µH
Tolerance : ±20%
Current Rating : 1.4A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 60 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 105MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
0
372 in stock
SDS680R-473M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 47µH
Tolerance : ±20%
Current Rating : 500mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 230 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 20MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 47µH
Tolerance : ±20%
Current Rating : 500mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 230 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 20MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
0
36688 in stock
SDS680R-475M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 4.7mH
Tolerance : ±20%
Current Rating : 60mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 13.9 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : 1MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 4.7mH
Tolerance : ±20%
Current Rating : 60mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 13.9 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : 1MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
0
4031 in stock
SDS680R-682M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 6.8µH
Tolerance : ±20%
Current Rating : 1.2A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 65 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 50MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 6.8µH
Tolerance : ±20%
Current Rating : 1.2A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 65 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 50MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
0
1400 in stock
SDS680R-683M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 68µH
Tolerance : ±20%
Current Rating : 400mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 290 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 15MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 68µH
Tolerance : ±20%
Current Rating : 400mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 290 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 15MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
0
224 in stock
SDS680R-684M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Discontinued at
Type : Wirewound
Material - Core : Ferrite
Inductance : 680µH
Tolerance : ±20%
Current Rating : 180mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 2.2 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : 3MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Discontinued at
Type : Wirewound
Material - Core : Ferrite
Inductance : 680µH
Tolerance : ±20%
Current Rating : 180mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 2.2 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : 3MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
0
100 in stock
SDS680R-685M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 6.8mH
Tolerance : ±20%
Current Rating : 40mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 25 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : 1MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS680R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 6.8mH
Tolerance : ±20%
Current Rating : 40mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 25 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : 1MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) : 0.115" (2.92mm)
0
4352 in stock
SDS850R-104M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS850R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 100µH
Tolerance : ±20%
Current Rating : 500mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 600 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.413" L x 0.315" W (10.50mm x 8.00mm)
Height - Seated (Max) : 0.189" (4.80mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS850R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 100µH
Tolerance : ±20%
Current Rating : 500mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 600 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.413" L x 0.315" W (10.50mm x 8.00mm)
Height - Seated (Max) : 0.189" (4.80mm)
0
22 in stock
SDS850R-184M
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS850R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 180µH
Tolerance : ±20%
Current Rating : 350mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 1.05 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.413" L x 0.315" W (10.50mm x 8.00mm)
Height - Seated (Max) : 0.189" (4.80mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS850R
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 180µH
Tolerance : ±20%
Current Rating : 350mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 1.05 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.413" L x 0.315" W (10.50mm x 8.00mm)
Height - Seated (Max) : 0.189" (4.80mm)
0
5519 in stock
SDS850R-222N
API Delevan
Manufacturer : API Delevan Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS850R
Part Status : Discontinued at
Type : Wirewound
Material - Core : Ferrite
Inductance : 2.2µH
Tolerance : ±30%
Current Rating : 2.5A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 40 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.413" L x 0.315" W (10.50mm x 8.00mm)
Height - Seated (Max) : 0.189" (4.80mm)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SDS850R
Part Status : Discontinued at
Type : Wirewound
Material - Core : Ferrite
Inductance : 2.2µH
Tolerance : ±30%
Current Rating : 2.5A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 40 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.413" L x 0.315" W (10.50mm x 8.00mm)
Height - Seated (Max) : 0.189" (4.80mm)
0
995 in stock
New Original Stock
Competitive Prices
One-stop
Customer Service
Contact Eruic
- krics@eruic.com
- krics@eruic.com
- Room 25i, Block A, Duhui 100 Building, Zhonghang Road, Huaqiang North Street, Futian District, Shenzhen, Guangdong
Customer service
Copyright © 2025 Eruic. All rights reserved.
web.ui.design.webdesign www.wzdzkf.com
Powered by www.wzdzkf.com
