Altera (Intel)
- Intel and Altera announced on June 1, 2015, that they had entered into a definitive agreement under which Intel would acquire Altera. The transaction closed December 28, 2015. The acquisition couples Intel’s leading-edge products and manufacturing process with Altera’s leading field-programmable gate array (FPGA) technology. The combination enables new classes of products that meet customer needs in the data center and Internet of Things (IoT) market segments.
Part Number
Manufacturer
Description
Unit Price
In Stock
Altera (Intel)
Manufacturer : Intel
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Enpirion®
Part Status : Active
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 9V
Voltage - Input (Max) : 16V
Voltage - Output 1 : 0.75 ~ 3.3 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 10A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : OCP, OTP, OVP, SCP, UVLO
Operating Temperature : -40°C ~ 125°C
Efficiency : 86.5%
Mounting Type : Surface Mount
Package / Case : 84-PowerBFQFN Module
Size / Dimension : 0.55" L x 0.47" W x 0.16" H (14.0mm x 12.0mm x 4.0mm)
Supplier Device Package : 84-QFN (14x12)
Control Features : -
0
100 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Tape & Reel (TR)
Series : Enpirion® 5300
Part Status : Obsolete
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.375V
Voltage - Input (Max) : 5.5V
Voltage - Output 1 : 0.8 ~ 3.3 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 1A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, OVP
Operating Temperature : 0°C ~ 70°C
Efficiency : 90%
Mounting Type : Surface Mount
Package / Case : 36-PowerDFN Module
Size / Dimension : 0.49" L x 0.32" W x 0.08" H (12.5mm x 8.1mm x 2.1mm)
Supplier Device Package : 36-DFN (12.5x8.1)
Control Features : Enable, Active High
0
100 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Tape & Reel (TR)
Series : Enpirion® 5300
Part Status : Obsolete
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.375V
Voltage - Input (Max) : 5.5V
Voltage - Output 1 : 0.8 ~ 3.3 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 1A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, OVP
Operating Temperature : -40°C ~ 85°C
Efficiency : 90%
Mounting Type : Surface Mount
Package / Case : 36-PowerDFN Module
Size / Dimension : 0.49" L x 0.32" W x 0.08" H (12.5mm x 8.1mm x 2.1mm)
Supplier Device Package : 36-DFN (12.5x8.1)
Control Features : Enable, Active High
0
100 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Enpirion® 5300
Part Status : Active
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.4V
Voltage - Input (Max) : 6.6V
Voltage - Output 1 : 0.6 ~ 6 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 1A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, SCP, UVLO
Operating Temperature : -40°C ~ 85°C
Efficiency : 94%
Mounting Type : Surface Mount
Package / Case : 20-PowerTQFN Module
Size / Dimension : 0.20" L x 0.16" W x 0.04" H (5.0mm x 4.0mm x 1.1mm)
Supplier Device Package : 20-QFN (5x4)
Control Features : Enable, Active High
0
9851 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Tape & Reel (TR)
Series : Enpirion® 5300
Part Status : Not For New Designs
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.4V
Voltage - Input (Max) : 6.6V
Voltage - Output 1 : 0.6 ~ 6 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 1A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, SCP, UVLO
Operating Temperature : -40°C ~ 85°C
Efficiency : 95%
Mounting Type : Surface Mount
Package / Case : 20-PowerTQFN Module
Size / Dimension : 0.20" L x 0.16" W x 0.04" H (5.0mm x 4.0mm x 1.1mm)
Supplier Device Package : 20-QFN (5x4)
Control Features : Enable, Active High
0
100 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Enpirion® 5300
Part Status : Active
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.4V
Voltage - Input (Max) : 5.5V
Voltage - Output 1 : 0.6 ~ 5.05 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 1.5A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, SCP, UVLO
Operating Temperature : -40°C ~ 85°C
Efficiency : 95%
Mounting Type : Surface Mount
Package / Case : 24-PowerTQFN Module
Size / Dimension : 0.24" L x 0.16" W x 0.04" H (6.0mm x 4.0mm x 1.1mm)
Supplier Device Package : 24-QFN (6x4)
Control Features : Enable, Active High
0
2658 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Enpirion® 5300
Part Status : Active
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.4V
Voltage - Input (Max) : 5.5V
Voltage - Output 1 : 0.6 ~ 4.9 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 2A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, SCP, UVLO
Operating Temperature : -40°C ~ 85°C
Efficiency : 95%
Mounting Type : Surface Mount
Package / Case : 24-PowerTQFN Module
Size / Dimension : 0.24" L x 0.16" W x 0.04" H (6.0mm x 4.0mm x 1.1mm)
Supplier Device Package : 24-QFN (6x4)
Control Features : Enable, Active High
0
7613 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Enpirion® 5300
Part Status : Active
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.4V
Voltage - Input (Max) : 5.5V
Voltage - Output 1 : 0.6 ~ 4.9 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 2A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, SCP, UVLO
Operating Temperature : -40°C ~ 85°C
Efficiency : 95%
Mounting Type : Surface Mount
Package / Case : 24-PowerTQFN Module
Size / Dimension : 0.24" L x 0.16" W x 0.04" H (6.0mm x 4.0mm x 1.1mm)
Supplier Device Package : 24-QFN (6x4)
Control Features : Enable, Active High
0
505 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Tape & Reel (TR)
Series : Enpirion® 5300
Part Status : Obsolete
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.375V
Voltage - Input (Max) : 5.5V
Voltage - Output 1 : 0.8 ~ 3.3 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 3A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, OVP, UVLO
Operating Temperature : 0°C ~ 70°C
Efficiency : 90%
Mounting Type : Surface Mount
Package / Case : 36-PowerDFN Module
Size / Dimension : 0.49" L x 0.32" W x 0.08" H (12.5mm x 8.1mm x 2.1mm)
Supplier Device Package : 36-DFN (12.5x8.1)
Control Features : Enable, Active High
0
100 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Tape & Reel (TR)
Series : Enpirion® 5300
Part Status : Obsolete
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.375V
Voltage - Input (Max) : 5.5V
Voltage - Output 1 : 0.8 ~ 3.3 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 3A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, OVP, UVLO
Operating Temperature : -40°C ~ 85°C
Efficiency : 90%
Mounting Type : Surface Mount
Package / Case : 36-PowerDFN Module
Size / Dimension : 0.49" L x 0.32" W x 0.08" H (12.5mm x 8.1mm x 2.1mm)
Supplier Device Package : 36-DFN (12.5x8.1)
Control Features : Enable, Active High
0
100 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Enpirion® 5300
Part Status : Active
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.375V
Voltage - Input (Max) : 6.6V
Voltage - Output 1 : 0.8 ~ 3.3 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 3A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, OVP, UVLO
Operating Temperature : -40°C ~ 85°C
Efficiency : 93%
Mounting Type : Surface Mount
Package / Case : 44-PowerQFN Module
Size / Dimension : 0.39" L x 0.30" W x 0.07" H (10.0mm x 7.5mm x 1.9mm)
Supplier Device Package : 44-QFN (10x5)
Control Features : Enable, Active High
0
100 in stock
Altera (Intel)
Manufacturer : Intel
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Enpirion® 5300
Part Status : Active
Type : Non-Isolated PoL Module
Number of Outputs : 1
Voltage - Input (Min) : 2.375V
Voltage - Input (Max) : 6.6V
Voltage - Output 1 : 0.75 ~ 6 V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 3A
Power (Watts) : -
Voltage - Isolation : -
Applications : ITE (Commercial)
Features : Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Operating Temperature : -40°C ~ 85°C
Efficiency : 93%
Mounting Type : Surface Mount
Package / Case : 44-PowerQFN Module
Size / Dimension : 0.39" L x 0.30" W x 0.07" H (10.0mm x 7.5mm x 1.9mm)
Supplier Device Package : 44-QFN (10x5)
Control Features : Enable, Active High
0
2187 in stock
