Triad Magnetics
- For over 70 years, consumer, commercial and industrial electronic devices have relied on innovative magnetics technology from Triad Magnetics. We offer solutions for power conversion, filtering, isolation and more. Our products include transformers for audio, gate drive, power, medical/dental, wall-mount and plug-in applications; as well as inductors for current sense, common mode, toroidal, filtering and power applications.
Today, you’ll find a wide range of Triad magnetic components in advanced computers, telecommunication systems, automation controls, audio devices and other equipment. Lewis W. Howard founded Triad during the 1940s in Venice, California. He was a UC Berkley graduate, a Wescon Trade Show cofounder and was recognized as an IEEE life member.
Part Number
Manufacturer
Description
Unit Price
In Stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Bulk
Series : CMT
Part Status : Active
Filter Type : Power Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 2mH @ 10kHz
Current Rating (Max) : 7.5A
DC Resistance (DCR) (Max) : 20 mOhm
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -
Ratings : -
Approvals : -
Features : ESD
Mounting Type : Through Hole
Size / Dimension : 1.450" L x 0.800" W (36.83mm x 20.32mm)
Height (Max) : 1.500" (38.10mm)
Package / Case : Vertical, 4 PC Pin
0
2142 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Bulk
Series : CMT
Part Status : Active
Filter Type : Power Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 4mH @ 10kHz
Current Rating (Max) : 5.2A
DC Resistance (DCR) (Max) : 40 mOhm
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -
Ratings : -
Approvals : -
Features : ESD
Mounting Type : Through Hole
Size / Dimension : 1.450" L x 0.800" W (36.83mm x 20.32mm)
Height (Max) : 1.500" (38.10mm)
Package / Case : Vertical, 4 PC Pin
0
2028 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Bulk
Series : CMT
Part Status : Active
Filter Type : Power Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 8mH @ 10kHz
Current Rating (Max) : 3.2A
DC Resistance (DCR) (Max) : 120 mOhm
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -
Ratings : -
Approvals : -
Features : ESD
Mounting Type : Through Hole
Size / Dimension : 1.450" L x 0.800" W (36.83mm x 20.32mm)
Height (Max) : 1.500" (38.10mm)
Package / Case : Vertical, 4 PC Pin
0
155 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Bulk
Series : CMT
Part Status : Active
Filter Type : Power Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 16mH @ 10kHz
Current Rating (Max) : 2.6A
DC Resistance (DCR) (Max) : 160 mOhm
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -
Ratings : -
Approvals : -
Features : ESD
Mounting Type : Through Hole
Size / Dimension : 1.450" L x 0.800" W (36.83mm x 20.32mm)
Height (Max) : 1.500" (38.10mm)
Package / Case : Vertical, 4 PC Pin
0
4859 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Bulk
Series : -
Part Status : Active
Frequency Range : 50Hz ~ 400Hz
Type : Invasive
Current Rating : 1A
Inductance : -
Energy Time (E.T.) : -
Turns Ratio - Primary:Secondary : -
Current Ratio : -
DC Resistance (DCR) : 125 mOhm Primary, 23 Ohm Secondary
Ratings : -
Mounting Type : Through Hole
Size / Dimension : 0.846" L x 0.945" W (21.50mm x 24.00mm)
Height - Seated (Max) : 0.709" (18.00mm)
Termination Style : PC Pin
0
636 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Bulk
Series : -
Part Status : Active
Frequency Range : 50Hz ~ 400Hz
Type : Invasive
Current Rating : 3A
Inductance : -
Energy Time (E.T.) : -
Turns Ratio - Primary:Secondary : 1:50
Current Ratio : -
DC Resistance (DCR) : 19.5 mOhm Primary, 23 Ohm Secondary
Ratings : -
Mounting Type : Through Hole
Size / Dimension : 0.846" L x 0.945" W (21.50mm x 24.00mm)
Height - Seated (Max) : 0.709" (18.00mm)
Termination Style : PC Pin
0
217 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Bulk
Series : -
Part Status : Active
Frequency Range : 50Hz ~ 400Hz
Type : Invasive
Current Rating : 10A
Inductance : -
Energy Time (E.T.) : -
Turns Ratio - Primary:Secondary : 1:166
Current Ratio : -
DC Resistance (DCR) : 2 mOhm Primary, 23 Ohm Secondary
Ratings : -
Mounting Type : Through Hole
Size / Dimension : 0.846" L x 0.945" W (21.50mm x 24.00mm)
Height - Seated (Max) : 0.709" (18.00mm)
Termination Style : PC Pin
0
236 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Bulk
Series : CSE
Part Status : Active
Frequency Range : 50Hz ~ 400Hz
Type : Invasive
Current Rating : 30A
Inductance : -
Energy Time (E.T.) : -
Turns Ratio - Primary:Secondary : 1:500
Current Ratio : -
DC Resistance (DCR) : 3 mOhm Primary, 21 Ohm Secondary
Ratings : -
Mounting Type : Through Hole
Size / Dimension : 0.860" L x 0.720" W (21.84mm x 18.29mm)
Height - Seated (Max) : 0.710" (18.03mm)
Termination Style : PC Pin
0
33347 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Bulk
Series : CSE
Part Status : Active
Frequency Range : 50Hz ~ 400Hz
Type : Invasive
Current Rating : 30A
Inductance : -
Energy Time (E.T.) : -
Turns Ratio - Primary:Secondary : 1:500
Current Ratio : -
DC Resistance (DCR) : 3 mOhm Primary, 21 Ohm Secondary
Ratings : -
Mounting Type : Through Hole
Size / Dimension : 0.875" L x 0.875" W (22.23mm x 22.23mm)
Height - Seated (Max) : 0.720" (18.29mm)
Termination Style : PC Pin
0
7588 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Frequency Range : 250kHz Min
Type : Invasive
Current Rating : 10A
Inductance : 80µH
Energy Time (E.T.) : -
Turns Ratio - Primary:Secondary : 1:200
Current Ratio : -
DC Resistance (DCR) : 550 mOhm Secondary
Ratings : -
Mounting Type : Surface Mount
Size / Dimension : 0.272" L x 0.303" W (6.90mm x 7.70mm)
Height - Seated (Max) : 0.210" (5.33mm)
Termination Style : Gull Wing
0
731 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Frequency Range : 250kHz Min
Type : Invasive
Current Rating : 10A
Inductance : 180µH
Energy Time (E.T.) : -
Turns Ratio - Primary:Secondary : 1:30
Current Ratio : -
DC Resistance (DCR) : 870 mOhm Secondary
Ratings : -
Mounting Type : Surface Mount
Size / Dimension : 0.272" L x 0.303" W (6.90mm x 7.70mm)
Height - Seated (Max) : 0.210" (5.33mm)
Termination Style : Gull Wing
0
718 in stock
Triad Magnetics
Manufacturer : Triad Magnetics
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Discontinued at
Frequency Range : 250kHz Min
Type : Invasive
Current Rating : 10A
Inductance : 320µH
Energy Time (E.T.) : -
Turns Ratio - Primary:Secondary : 1:40
Current Ratio : -
DC Resistance (DCR) : 1.14 Ohm Secondary
Ratings : -
Mounting Type : Surface Mount
Size / Dimension : 0.272" L x 0.303" W (6.90mm x 7.70mm)
Height - Seated (Max) : 0.210" (5.33mm)
Termination Style : Gull Wing
0
359 in stock
