Comchip Technology
- Comchip Technology Corporation leads in the design and manufacture of SMD discrete semiconductors. With innovative research and patented manufacturing capabilities, Comchip offers bridge rectifiers, fast efficient rectifiers, switching diodes, Zener diodes, Schottky diodes, TVS and ESD surge protectors. We have the right diode for your application. Comchip Technology is the first manufacturer to standardize DFN/flat chip packaging that are RoHS compliant and zero Tin-Whisker potential by using gold termination. DFN packages are available in SOD-323F (1005), SOD-523F (0603), SOD-723F (0503), SOD-923F (0402) and 0201 sizes.
Comchip products are suitable for vast array of applications including lighting, automotive, industrial computers, TFT-LCD panels, network/telecom, medical, portable and consumer electronics, as well as high reliability applications that can benefit from the zero Tin-Whisker potential.. To ensure superior quality and reliability, Comchip’s quality control process and factory are TS16949, ISO9001, and ISO14001 certified. As an added layer of security, Comchip’s bridge rectifier and TVS have passed UL testing for safety device application. Many Comchip diodes meet the automotive stress test requirements AEC-Q101 and are well suited for automotive as well as high reliability application.
Part Number
Manufacturer
Description
Unit Price
In Stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 12V
Voltage - Breakdown (Min) : 13.5V
Voltage - Clamping (Max) @ Ipp : 23.7V
Current - Peak Pulse (10/1000µs) : 5.9A (8/20µs)
Power - Peak Pulse : 140W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 30pF @ 1MHz
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : SOD-923
Supplier Device Package : 0402/SOD-923F
0
23678 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 3.3V
Voltage - Breakdown (Min) : 5V
Voltage - Clamping (Max) @ Ipp : 14.1V
Current - Peak Pulse (10/1000µs) : 11.2A (8/20µs)
Power - Peak Pulse : 158W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 25pF @ 1MHz
Operating Temperature : -40°C ~ 125°C (TA)
Mounting Type : Surface Mount
Package / Case : SOD-923
Supplier Device Package : 0402/SOD-923F
0
145166 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 3.3V
Voltage - Breakdown (Min) : 5V
Voltage - Clamping (Max) @ Ipp : 10.4V
Current - Peak Pulse (10/1000µs) : 9.8A (8/20µs)
Power - Peak Pulse : 102W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 80pF @ 1MHz
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : SOD-923
Supplier Device Package : 0402/SOD-923F
0
120491 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 5V
Voltage - Breakdown (Min) : 5.6V
Voltage - Clamping (Max) @ Ipp : 18.6V
Current - Peak Pulse (10/1000µs) : 9.4A (8/20µs)
Power - Peak Pulse : 174W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 15pF @ 1MHz
Operating Temperature : -40°C ~ 125°C (TA)
Mounting Type : Surface Mount
Package / Case : SOD-923
Supplier Device Package : 0402/SOD-923F
0
237800 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 5V
Voltage - Breakdown (Min) : 5.4V
Voltage - Clamping (Max) @ Ipp : 9.8V
Current - Peak Pulse (10/1000µs) : 1A (8/20µs)
Power - Peak Pulse : 9.8W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 0.5pF @ 1MHz
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : SOD-923
Supplier Device Package : 0402/SOD-923F
0
10610 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 5V (Max)
Voltage - Breakdown (Min) : 5.6V
Voltage - Clamping (Max) @ Ipp : 13V
Current - Peak Pulse (10/1000µs) : 3A (8/20µs)
Power - Peak Pulse : 39W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 3pF @ 1MHz
Operating Temperature : -40°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : SC-101, SOT-883
Supplier Device Package : SOT-883
0
3002 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 12V (Max)
Voltage - Breakdown (Min) : 14V
Voltage - Clamping (Max) @ Ipp : 23V
Current - Peak Pulse (10/1000µs) : 5A (8/20µs)
Power - Peak Pulse : 115W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 30pF @ 1MHz
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0402 (1006 Metric)
Supplier Device Package : 0402C/SOD-923F
0
1365 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 12V (Max)
Voltage - Breakdown (Min) : 13.5V
Voltage - Clamping (Max) @ Ipp : 22V
Current - Peak Pulse (10/1000µs) : 5A (8/20µs)
Power - Peak Pulse : 110W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 60pF @ 1MHz
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0402 (1006 Metric)
Supplier Device Package : 0402/SOD-923F
0
3960 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 24V (Max)
Voltage - Breakdown (Min) : 26.5V
Voltage - Clamping (Max) @ Ipp : 46V
Current - Peak Pulse (10/1000µs) : 3A (8/20µs)
Power - Peak Pulse : 138W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 13pF @ 1MHz
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0402 (1006 Metric)
Supplier Device Package : 0402C/SOD-923F
0
9880 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 24V (Max)
Voltage - Breakdown (Min) : 26.5V
Voltage - Clamping (Max) @ Ipp : 42V
Current - Peak Pulse (10/1000µs) : 2.5A (8/20µs)
Power - Peak Pulse : 105W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 35pF @ 1MHz
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0402 (1006 Metric)
Supplier Device Package : 0402/SOD-923F
0
21133 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 3.3V (Max)
Voltage - Breakdown (Min) : 3.6V
Voltage - Clamping (Max) @ Ipp : 13V
Current - Peak Pulse (10/1000µs) : 5A (8/20µs)
Power - Peak Pulse : 65W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 6pF @ 1MHz
Operating Temperature : -55°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0402 (1006 Metric)
Supplier Device Package : 0402C/SOD-923F
0
12790 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 3.3V (Max)
Voltage - Breakdown (Min) : 3.6V
Voltage - Clamping (Max) @ Ipp : 6.2V
Current - Peak Pulse (10/1000µs) : 17A (8/20µs)
Power - Peak Pulse : 180W
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 20pF @ 1MHz
Operating Temperature : -40°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0402 (1006 Metric)
Supplier Device Package : 0402C/SOD-923F
0
100 in stock
