Comchip Technology
- Comchip Technology Corporation leads in the design and manufacture of SMD discrete semiconductors. With innovative research and patented manufacturing capabilities, Comchip offers bridge rectifiers, fast efficient rectifiers, switching diodes, Zener diodes, Schottky diodes, TVS and ESD surge protectors. We have the right diode for your application. Comchip Technology is the first manufacturer to standardize DFN/flat chip packaging that are RoHS compliant and zero Tin-Whisker potential by using gold termination. DFN packages are available in SOD-323F (1005), SOD-523F (0603), SOD-723F (0503), SOD-923F (0402) and 0201 sizes.
Comchip products are suitable for vast array of applications including lighting, automotive, industrial computers, TFT-LCD panels, network/telecom, medical, portable and consumer electronics, as well as high reliability applications that can benefit from the zero Tin-Whisker potential.. To ensure superior quality and reliability, Comchip’s quality control process and factory are TS16949, ISO9001, and ISO14001 certified. As an added layer of security, Comchip’s bridge rectifier and TVS have passed UL testing for safety device application. Many Comchip diodes meet the automotive stress test requirements AEC-Q101 and are well suited for automotive as well as high reliability application.
Part Number
Manufacturer
Description
Unit Price
In Stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 48V
Voltage - Breakdown (Min) : 53.3V
Voltage - Clamping (Max) @ Ipp : 77.4V
Current - Peak Pulse (10/1000µs) : 5.17A
Power - Peak Pulse : 400W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AC, SMA
Supplier Device Package : SMA (DO-214AC)
0
4730 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 12V
Voltage - Breakdown (Min) : 13.3V
Voltage - Clamping (Max) @ Ipp : 19.9V
Current - Peak Pulse (10/1000µs) : 30.15A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
2497 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 12V
Voltage - Breakdown (Min) : 13.3V
Voltage - Clamping (Max) @ Ipp : 19.9V
Current - Peak Pulse (10/1000µs) : 30.15A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
3000 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 24V
Voltage - Breakdown (Min) : 26.7V
Voltage - Clamping (Max) @ Ipp : 38.9V
Current - Peak Pulse (10/1000µs) : 15.42A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
1662 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 24V
Voltage - Breakdown (Min) : 26.7V
Voltage - Clamping (Max) @ Ipp : 38.9V
Current - Peak Pulse (10/1000µs) : 15.42A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
2475 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 26V
Voltage - Breakdown (Min) : 28.9V
Voltage - Clamping (Max) @ Ipp : 42.1V
Current - Peak Pulse (10/1000µs) : 14.25A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
3000 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 26V
Voltage - Breakdown (Min) : 28.9V
Voltage - Clamping (Max) @ Ipp : 42.1V
Current - Peak Pulse (10/1000µs) : 14.25A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
2603 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 30V
Voltage - Breakdown (Min) : 33.3V
Voltage - Clamping (Max) @ Ipp : 48.4V
Current - Peak Pulse (10/1000µs) : 12.4A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : DO-214AA (SMB)
0
100 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 36V
Voltage - Breakdown (Min) : 40V
Voltage - Clamping (Max) @ Ipp : 58.1V
Current - Peak Pulse (10/1000µs) : 10.33A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
1942 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 36V
Voltage - Breakdown (Min) : 40V
Voltage - Clamping (Max) @ Ipp : 58.1V
Current - Peak Pulse (10/1000µs) : 10.33A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
289 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 40V
Voltage - Breakdown (Min) : 44.4V
Voltage - Clamping (Max) @ Ipp : 64.5V
Current - Peak Pulse (10/1000µs) : 9.3A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
2973 in stock
Comchip Technology
Manufacturer : Comchip Technology
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Automotive, AEC-Q101
Part Status : Active
Type : Zener
Unidirectional Channels : 1
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 40V
Voltage - Breakdown (Min) : 44.4V
Voltage - Clamping (Max) @ Ipp : 64.5V
Current - Peak Pulse (10/1000µs) : 9.3A
Power - Peak Pulse : 600W
Power Line Protection : No
Applications : Automotive
Capacitance @ Frequency : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB (DO-214AA)
0
2957 in stock
