- CnC Tech takes pride in providing reliable industrial connection and interconnect solutions when high quality parts and competitive pricing are important factors. With 17 years of experience, CnC Tech is committed to meeting the demands of an ever changing market.
CnC Tech’s product line includes raw wire, magnet wire, power cords, connectors, interconnects, USB cables, modular cables, standard cables, flat ribbon cables, and board level components, like IC sockets, IDC's, PLCC sockets and USB connectors.
CnC Tech also specializes in fast turnaround custom cables and interconnects with original or equivalent connectors according to customers’ requirements. From flat ribbon cable interconnections, specialized custom cables to power cords of all kinds, CnC Tech’s capabilities are well known in the industry.
Part Number
Manufacturer
Description
Unit Price
In Stock
CnC Tech
Manufacturer : CNC Tech
Series : -
Part Status : Active
Cable Type : Flat Cable
Number of Conductors : 20
Pitch : 0.025" (0.64mm)
Length : 100.0' (30.48m)
Wire Gauge : 30 AWG
Conductor Strand : 7 Strands / 38 AWG
Shielding : Unshielded
Jacket Color : Gray
Ribbon Thickness : 0.026" (0.66mm)
Ribbon Width : 0.500" (12.70mm)
Jacket (Insulation) Material : Poly-Vinyl Chloride (PVC)
Voltage : 150V
Operating Temperature : 105°C
Ratings : UL Style 2678
Features : -
0
28 in stock
CnC Tech
Manufacturer : CNC Tech
Series : -
Part Status : Active
Cable Type : Flat Cable
Number of Conductors : 20
Pitch : 0.025" (0.64mm)
Length : 250.0' (76.20m)
Wire Gauge : 30 AWG
Conductor Strand : 7 Strands / 38 AWG
Shielding : Unshielded
Jacket Color : Gray
Ribbon Thickness : 0.026" (0.66mm)
Ribbon Width : 0.500" (12.70mm)
Jacket (Insulation) Material : Poly-Vinyl Chloride (PVC)
Voltage : 150V
Operating Temperature : 105°C
Ratings : UL Style 2678
Features : -
0
31 in stock
CnC Tech
Manufacturer : CNC Tech
Series : -
Part Status : Active
Cable Type : Flat Cable
Number of Conductors : 26
Pitch : 0.025" (0.64mm)
Length : 100.0' (30.48m)
Wire Gauge : 30 AWG
Conductor Strand : 7 Strands / 38 AWG
Shielding : Unshielded
Jacket Color : Gray
Ribbon Thickness : 0.026" (0.66mm)
Ribbon Width : 0.650" (16.51mm)
Jacket (Insulation) Material : Poly-Vinyl Chloride (PVC)
Voltage : 150V
Operating Temperature : 105°C
Ratings : UL Style 2678
Features : -
0
19 in stock
CnC Tech
Manufacturer : CNC Tech
Series : -
Part Status : Active
Cable Type : Flat Cable
Number of Conductors : 26
Pitch : 0.025" (0.64mm)
Length : 250.0' (76.20m)
Wire Gauge : 30 AWG
Conductor Strand : 7 Strands / 38 AWG
Shielding : Unshielded
Jacket Color : Gray
Ribbon Thickness : 0.026" (0.66mm)
Ribbon Width : 0.650" (16.51mm)
Jacket (Insulation) Material : Poly-Vinyl Chloride (PVC)
Voltage : 150V
Operating Temperature : 105°C
Ratings : UL Style 2678
Features : -
0
16 in stock
CnC Tech
Manufacturer : CNC Tech
Series : -
Part Status : Active
Cable Type : Flat Cable
Number of Conductors : 40
Pitch : 0.025" (0.64mm)
Length : 100.0' (30.48m)
Wire Gauge : 30 AWG
Conductor Strand : 7 Strands / 38 AWG
Shielding : Unshielded
Jacket Color : Gray
Ribbon Thickness : 0.026" (0.66mm)
Ribbon Width : 1.000" (25.40mm)
Jacket (Insulation) Material : Poly-Vinyl Chloride (PVC)
Voltage : 150V
Operating Temperature : 105°C
Ratings : UL Style 2678
Features : -
0
12 in stock
CnC Tech
Manufacturer : CNC Tech
Series : -
Part Status : Active
Cable Type : Flat Cable
Number of Conductors : 40
Pitch : 0.025" (0.64mm)
Length : 250.0' (76.20m)
Wire Gauge : 30 AWG
Conductor Strand : 7 Strands / 38 AWG
Shielding : Unshielded
Jacket Color : Gray
Ribbon Thickness : 0.026" (0.66mm)
Ribbon Width : 1.000" (25.40mm)
Jacket (Insulation) Material : Poly-Vinyl Chloride (PVC)
Voltage : 150V
Operating Temperature : 105°C
Ratings : UL Style 2678
Features : -
0
9 in stock
CnC Tech
Manufacturer : CNC Tech
Series : -
Part Status : Active
Cable Type : Flat Cable
Number of Conductors : 50
Pitch : 0.025" (0.64mm)
Length : 100.0' (30.48m)
Wire Gauge : 30 AWG
Conductor Strand : 7 Strands / 38 AWG
Shielding : Unshielded
Jacket Color : Gray
Ribbon Thickness : 0.026" (0.66mm)
Ribbon Width : 1.250" (31.75mm)
Jacket (Insulation) Material : Poly-Vinyl Chloride (PVC)
Voltage : 150V
Operating Temperature : 105°C
Ratings : UL Style 2678
Features : -
0
19 in stock
CnC Tech
Manufacturer : CNC Tech
Series : -
Part Status : Active
Cable Type : Flat Cable
Number of Conductors : 50
Pitch : 0.025" (0.64mm)
Length : 250.0' (76.20m)
Wire Gauge : 30 AWG
Conductor Strand : 7 Strands / 38 AWG
Shielding : Unshielded
Jacket Color : Gray
Ribbon Thickness : 0.026" (0.66mm)
Ribbon Width : 1.250" (31.75mm)
Jacket (Insulation) Material : Poly-Vinyl Chloride (PVC)
Voltage : 150V
Operating Temperature : 105°C
Ratings : UL Style 2678
Features : -
0
20 in stock
CnC Tech
Manufacturer : CNC Tech
Packaging : Tray
Series : -
Part Status : Active
Connector Type : Header
Contact Type : Male Pin
Pitch - Mating : 0.100" (2.54mm)
Number of Positions : 10
Number of Rows : 2
Row Spacing - Mating : 0.100" (2.54mm)
Number of Positions Loaded : All
Style : Board to Cable/Wire
Shrouding : Shrouded - 4 Wall
Mounting Type : Through Hole
Termination : Solder
Fastening Type : Latch Lock/Eject Hooks, Short
Contact Length - Mating : -
Contact Length - Post : 0.134" (3.40mm)
Overall Contact Length : -
Insulation Height : -
Contact Shape : Square
Contact Finish - Mating : Gold
Contact Finish Thickness - Mating : Flash
Contact Finish - Post : -
Contact Material : Brass
Insulation Material : Polybutylene Terephthalate (PBT)
Features : Keying Slot
Operating Temperature : -40°C ~ 105°C
Ingress Protection : -
Material Flammability Rating : UL94 V-0
Insulation Color : -
Current Rating : 1A
Voltage Rating : -
0
936 in stock
CnC Tech
Manufacturer : CNC Tech
Packaging : Tray
Series : -
Part Status : Active
Connector Type : Header
Contact Type : Male Pin
Pitch - Mating : 0.100" (2.54mm)
Number of Positions : 10
Number of Rows : 2
Row Spacing - Mating : 0.100" (2.54mm)
Number of Positions Loaded : All
Style : Board to Cable/Wire
Shrouding : Shrouded - 4 Wall
Mounting Type : Through Hole
Termination : Solder
Fastening Type : Latch Lock/Eject Hooks, Long
Contact Length - Mating : -
Contact Length - Post : 0.134" (3.40mm)
Overall Contact Length : -
Insulation Height : -
Contact Shape : Square
Contact Finish - Mating : Gold
Contact Finish Thickness - Mating : Flash
Contact Finish - Post : -
Contact Material : Brass
Insulation Material : Polybutylene Terephthalate (PBT)
Features : Keying Slot
Operating Temperature : -40°C ~ 105°C
Ingress Protection : -
Material Flammability Rating : UL94 V-0
Insulation Color : -
Current Rating : 1A
Voltage Rating : -
0
936 in stock
CnC Tech
Manufacturer : CNC Tech
Packaging : Tray
Series : -
Part Status : Active
Connector Type : Header
Contact Type : Male Pin
Pitch - Mating : 0.100" (2.54mm)
Number of Positions : 10
Number of Rows : 2
Row Spacing - Mating : 0.100" (2.54mm)
Number of Positions Loaded : All
Style : Board to Cable/Wire
Shrouding : Shrouded - 4 Wall
Mounting Type : Through Hole, Right Angle
Termination : Solder
Fastening Type : Latch Lock/Eject Hooks, Short
Contact Length - Mating : -
Contact Length - Post : 0.134" (3.40mm)
Overall Contact Length : -
Insulation Height : 0.323" (8.20mm)
Contact Shape : Square
Contact Finish - Mating : Gold
Contact Finish Thickness - Mating : Flash
Contact Finish - Post : -
Contact Material : Brass
Insulation Material : Polybutylene Terephthalate (PBT)
Features : -
Operating Temperature : -40°C ~ 105°C
Ingress Protection : -
Material Flammability Rating : UL94 V-0
Insulation Color : -
Current Rating : 1A
Voltage Rating : -
0
936 in stock
CnC Tech
Manufacturer : CNC Tech
Packaging : Tray
Series : -
Part Status : Active
Connector Type : Header
Contact Type : Male Pin
Pitch - Mating : 0.100" (2.54mm)
Number of Positions : 10
Number of Rows : 2
Row Spacing - Mating : 0.100" (2.54mm)
Number of Positions Loaded : All
Style : Board to Cable/Wire
Shrouding : Shrouded - 4 Wall
Mounting Type : Through Hole, Right Angle
Termination : Solder
Fastening Type : Latch Lock/Eject Hooks, Long
Contact Length - Mating : -
Contact Length - Post : 0.134" (3.40mm)
Overall Contact Length : -
Insulation Height : 0.323" (8.20mm)
Contact Shape : Square
Contact Finish - Mating : Gold
Contact Finish Thickness - Mating : Flash
Contact Finish - Post : -
Contact Material : Brass
Insulation Material : Polybutylene Terephthalate (PBT)
Features : -
Operating Temperature : -40°C ~ 105°C
Ingress Protection : -
Material Flammability Rating : UL94 V-0
Insulation Color : -
Current Rating : 1A
Voltage Rating : -
0
936 in stock
