Central Semiconductor
- Since 1974, Central Semiconductor has manufactured innovative discrete semiconductors used in electronic products worldwide. Devices currently include standard and custom small signal transistors, bipolar power transistors, MOSFETs, diodes, rectifiers, protection devices, current limiting diodes, bridge rectifiers, thyristors, and silicon carbide devices. Central’s devices are available in industry standard surface mount and through-hole packages, bare die, TLMs (Tiny Leadless Modules™), and MDMs (Multi Discrete Modules™). Central has earned a reputation as a manufacturer of the highest quality products consistently delivered on-time, and a provider of exceptional value-added services.
Part Number
Manufacturer
Description
Unit Price
In Stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Voltage - Zener (Nom) (Vz) : 15V
Tolerance : ±5%
Power - Max : 5W
Impedance (Max) (Zzt) : 2.5 Ohms
Current - Reverse Leakage @ Vr : 1µA @ 11.5V
Voltage - Forward (Vf) (Max) @ If : 1.2V @ 1A
Operating Temperature : -65°C ~ 200°C
Mounting Type : Through Hole
Package / Case : DO-201AA, DO-27, Axial
Supplier Device Package : DO-201
0
1228 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Voltage - Zener (Nom) (Vz) : 17V
Tolerance : ±5%
Power - Max : 5W
Impedance (Max) (Zzt) : 2.5 Ohms
Current - Reverse Leakage @ Vr : 500nA @ 12.9V
Voltage - Forward (Vf) (Max) @ If : 1.2V @ 1A
Operating Temperature : -65°C ~ 200°C
Mounting Type : Through Hole
Package / Case : DO-201AA, DO-27, Axial
Supplier Device Package : DO-201
0
3716 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Voltage - Zener (Nom) (Vz) : 20V
Tolerance : ±5%
Power - Max : 5W
Impedance (Max) (Zzt) : 3 Ohms
Current - Reverse Leakage @ Vr : 500nA @ 15.2V
Voltage - Forward (Vf) (Max) @ If : 1.2V @ 1A
Operating Temperature : -65°C ~ 200°C
Mounting Type : Through Hole
Package / Case : DO-201AA, DO-27, Axial
Supplier Device Package : DO-201
0
1407 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Voltage - Zener (Nom) (Vz) : 22V
Tolerance : ±5%
Power - Max : 5W
Impedance (Max) (Zzt) : 3.5 Ohms
Current - Reverse Leakage @ Vr : 500nA @ 16.7V
Voltage - Forward (Vf) (Max) @ If : 1.2V @ 1A
Operating Temperature : -65°C ~ 200°C
Mounting Type : Through Hole
Package / Case : DO-201AA, DO-27, Axial
Supplier Device Package : DO-201
0
1987 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Voltage - Zener (Nom) (Vz) : 24V
Tolerance : ±5%
Power - Max : 5W
Impedance (Max) (Zzt) : 3.5 Ohms
Current - Reverse Leakage @ Vr : 500nA @ 18.2V
Voltage - Forward (Vf) (Max) @ If : 1.2V @ 1A
Operating Temperature : -65°C ~ 200°C
Mounting Type : Through Hole
Package / Case : DO-201AA, DO-27, Axial
Supplier Device Package : DO-201
0
3641 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Voltage - Zener (Nom) (Vz) : 33V
Tolerance : ±5%
Power - Max : 5W
Impedance (Max) (Zzt) : 10 Ohms
Current - Reverse Leakage @ Vr : 500nA @ 25.1V
Voltage - Forward (Vf) (Max) @ If : 1.2V @ 1A
Operating Temperature : -65°C ~ 200°C
Mounting Type : Through Hole
Package / Case : DO-201AA, DO-27, Axial
Supplier Device Package : DO-201
0
2721 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : -
Series : -
Part Status : Obsolete
FET Type : N-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 100V
Current - Continuous Drain (Id) @ 25°C : 3A (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 10V
Rds On (Max) @ Id, Vgs : 150 mOhm @ 2A, 10V
Vgs(th) (Max) @ Id : 4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 15nC @ 10V
Vgs (Max) : 20V
Input Capacitance (Ciss) (Max) @ Vds : 975pF @ 25V
FET Feature : -
Power Dissipation (Max) : 2W (Ta)
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-223
Package / Case : TO-261-4, TO-261AA
0
100 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
FET Type : N-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 100V
Current - Continuous Drain (Id) @ 25°C : 3A (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 10V
Rds On (Max) @ Id, Vgs : 150 mOhm @ 2A, 10V
Vgs(th) (Max) @ Id : 4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 15nC @ 10V
Vgs (Max) : 20V
Input Capacitance (Ciss) (Max) @ Vds : 975pF @ 25V
FET Feature : -
Power Dissipation (Max) : 2W (Ta)
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-223
Package / Case : TO-261-4, TO-261AA
0
100 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) : 5A
Voltage - Forward (Vf) (Max) @ If : 550mV @ 5A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 3mA @ 40V
Capacitance @ Vr, F : -
Mounting Type : Surface Mount
Package / Case : TO-261-4, TO-261AA
Supplier Device Package : SOT-223
Operating Temperature - Junction : -65°C ~ 150°C
0
4331 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Transistor Type : NPN
Current - Collector (Ic) (Max) : 600mA
Voltage - Collector Emitter Breakdown (Max) : 40V
Vce Saturation (Max) @ Ib, Ic : 1V @ 50mA, 500mA
Current - Collector Cutoff (Max) : 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 100 @ 150mA, 10V
Power - Max : 2W
Frequency - Transition : 300MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-261-4, TO-261AA
Supplier Device Package : SOT-223
0
6794 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Transistor Type : PNP
Current - Collector (Ic) (Max) : 600mA
Voltage - Collector Emitter Breakdown (Max) : 60V
Vce Saturation (Max) @ Ib, Ic : 1.6V @ 50mA, 500mA
Current - Collector Cutoff (Max) : 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 100 @ 150mA, 10V
Power - Max : 2W
Frequency - Transition : 200MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-261-4, TO-261AA
Supplier Device Package : SOT-223
0
360 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Transistor Type : NPN
Current - Collector (Ic) (Max) : 1A
Voltage - Collector Emitter Breakdown (Max) : 80V
Vce Saturation (Max) @ Ib, Ic : 500mV @ 50mA, 500mA
Current - Collector Cutoff (Max) : 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 100 @ 150mA, 10V
Power - Max : 2W
Frequency - Transition : 400MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-261-4, TO-261AA
Supplier Device Package : SOT-223
0
3392 in stock
