- Amgis is a manufacturer/importer of high frequency inductive components and AC/DC power supplies. We import and export components daily through our purchasing and sales networking systems, including India, Asia, Europe, and the United States. The majority of our standard components are manufactured at our ISO9001 certified facility located in Salem, India. Our strength is in our service, having qualified engineers at all of our locations, and exceptional customer service teams, we can qualify most requirements and have answers to requests within hours instead of days.
Amgis was originally a subsidiary of the Talema Group and carries all the Talema high frequency component lines, including power inductors, common mode chokes, current sensors, telecom products, and networking products. Also, we have diversified into the switching power supply market, including standard lines and custom designs, both open style and enclosed. By drawing upon the resources of our extensive worldwide network, Amgis provides its customers with high quality components at very competitive prices.
Part Number
Manufacturer
Description
Unit Price
In Stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Transformer Type : Isolation and Data Interface (Encapsulated)
Inductance : 25mH
Energy Time (E.T.) : -
Turns Ratio - Primary:Secondary : 1:1:2:2
Mounting Type : Surface Mount
Size / Dimension : 0.504" L x 0.346" W (12.80mm x 8.80mm)
Height - Seated (Max) : 0.246" (6.25mm)
Operating Temperature : -40°C ~ 85°C
0
3267 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Tray
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 114µH
Tolerance : ±20%
Current Rating : 2.22A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 100 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Through Hole
Package / Case : Radial
Supplier Device Package : -
Size / Dimension : 0.827" L x 0.449" W (21.00mm x 11.40mm)
Height - Seated (Max) : 0.937" (23.80mm)
0
66 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Tray
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 110µH
Tolerance : ±20%
Current Rating : 3A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 90 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Through Hole
Package / Case : Radial
Supplier Device Package : -
Size / Dimension : 0.949" L x 0.598" W (24.10mm x 15.20mm)
Height - Seated (Max) : 1.059" (26.90mm)
0
604 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Tray
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 17µH
Tolerance : ±20%
Current Rating : 3A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 50 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Through Hole
Package / Case : Radial
Supplier Device Package : -
Size / Dimension : 0.580" L x 0.340" W (14.73mm x 8.64mm)
Height - Seated (Max) : 0.690" (17.53mm)
0
794 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Tray
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 38µH
Tolerance : ±20%
Current Rating : 3A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 50 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Through Hole
Package / Case : Radial
Supplier Device Package : -
Size / Dimension : 0.827" L x 0.449" W (21.00mm x 11.40mm)
Height - Seated (Max) : 0.937" (23.80mm)
0
59 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Tray
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 77µH
Tolerance : ±20%
Current Rating : 3A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 80 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Through Hole
Package / Case : Radial
Supplier Device Package : -
Size / Dimension : 0.827" L x 0.449" W (21.00mm x 11.40mm)
Height - Seated (Max) : 0.937" (23.80mm)
0
270 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Tray
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 19µH
Tolerance : ±20%
Current Rating : 4.5A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 20 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Through Hole
Package / Case : Radial
Supplier Device Package : -
Size / Dimension : 0.827" L x 0.449" W (21.00mm x 11.40mm)
Height - Seated (Max) : 0.937" (23.80mm)
0
68 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 118µH
Tolerance : ±20%
Current Rating : 380mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 1.2 Ohm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.441" L x 0.433" W (11.20mm x 11.00mm)
Height - Seated (Max) : 0.301" (7.65mm)
0
166 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 173µH
Tolerance : ±20%
Current Rating : 540mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 600 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.559" L x 0.551" W (14.20mm x 14.00mm)
Height - Seated (Max) : 0.337" (8.55mm)
0
428 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 248µH
Tolerance : ±20%
Current Rating : 830mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 600 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.614" L x 0.591" W (15.60mm x 15.00mm)
Height - Seated (Max) : 0.388" (9.85mm)
0
785 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 54µH
Tolerance : ±20%
Current Rating : 1A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 200 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.559" L x 0.551" W (14.20mm x 14.00mm)
Height - Seated (Max) : 0.337" (8.55mm)
0
574 in stock
AlfaMag Electronics (AMGIS)
Manufacturer : Amgis, LLC
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SH150
Part Status : Active
Type : Toroidal
Material - Core : Iron Powder
Inductance : 168µH
Tolerance : ±20%
Current Rating : 1.02A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 400 mOhm
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.614" L x 0.591" W (15.60mm x 15.00mm)
Height - Seated (Max) : 0.388" (9.85mm)
0
484 in stock
