Allegro MicroSystems, LLC.
- Allegro MicroSystems, (Allegro) is a leader in developing high-performance power and sensing semiconductors. Allegro's innovative solutions serve high-growth applications within the automotive market, with additional focus on industrial and consumer/computing solutions. Allegro is headquartered in Manchester, New Hampshire (USA) with design, applications, and sales support centers located worldwide.
Part Number
Manufacturer
Description
Unit Price
In Stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : -
Part Status : Not For New Designs
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 50A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 40mV/A
Frequency : DC ~ 120kHz
Linearity : ±1.8%
Accuracy : ±7.5%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 3µs
Current - Supply (Max) : 14mA
Operating Temperature : -40°C ~ 125°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Formed Leads, PFF
0
100 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : -
Part Status : Obsolete
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 50A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 40mV/A
Frequency : DC ~ 120kHz
Linearity : ±1%
Accuracy : ±5%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 3µs
Current - Supply (Max) : 14mA
Operating Temperature : -20°C ~ 85°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CA Formed Leads
0
100 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : -
Part Status : Obsolete
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 100A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 20mV/A
Frequency : DC ~ 120kHz
Linearity : ±1.75%
Accuracy : ±7%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 3µs
Current - Supply (Max) : 14mA
Operating Temperature : -20°C ~ 85°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CA Formed Leads
0
100 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : -
Part Status : Not For New Designs
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 50A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 40mV/A
Frequency : DC ~ 120kHz
Linearity : ±1%
Accuracy : ±5%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 3µs
Current - Supply (Max) : 14mA
Operating Temperature : -20°C ~ 85°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Formed Leads, PFF
0
6624 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : -
Part Status : Not For New Designs
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 100A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 20mV/A
Frequency : DC ~ 120kHz
Linearity : ±1.75%
Accuracy : ±7%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 3µs
Current - Supply (Max) : 14mA
Operating Temperature : -20°C ~ 85°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Formed Leads, PFF
0
1632 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : Automotive, AEC-Q100
Part Status : Not For New Designs
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 200A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 10mV/A
Frequency : DC ~ 120kHz
Linearity : ±1%
Accuracy : ±1.2%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 4µs
Current - Supply (Max) : 13.5mA
Operating Temperature : -40°C ~ 85°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Formed Leads, PFF
0
6094 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : Automotive, AEC-Q100
Part Status : Not For New Designs
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 200A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 10mV/A
Frequency : DC ~ 120kHz
Linearity : ±1%
Accuracy : ±1.2%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 4µs
Current - Supply (Max) : 13.5mA
Operating Temperature : -40°C ~ 85°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Straight Leads
0
1679 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : Automotive, AEC-Q100
Part Status : Not For New Designs
For Measuring : DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 200A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 20mV/A
Frequency : DC ~ 120kHz
Linearity : ±1%
Accuracy : ±1.2%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 4µs
Current - Supply (Max) : 13.5mA
Operating Temperature : -40°C ~ 85°C
Polarization : Unidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Formed Leads, PFF
0
3380 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : Automotive, AEC-Q100
Part Status : Not For New Designs
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 150A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 13.3mV/A
Frequency : DC ~ 120kHz
Linearity : ±1%
Accuracy : ±1.6%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 4µs
Current - Supply (Max) : 13.5mA
Operating Temperature : -40°C ~ 125°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Formed Leads, PFF
0
1968 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : Automotive, AEC-Q100
Part Status : Not For New Designs
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 150A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 13.3mV/A
Frequency : DC ~ 120kHz
Linearity : ±1%
Accuracy : ±1.6%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 4µs
Current - Supply (Max) : 13.5mA
Operating Temperature : -40°C ~ 125°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Straight Leads
0
4623 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : Automotive, AEC-Q100
Part Status : Not For New Designs
For Measuring : DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 150A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 26.7mV/A
Frequency : DC ~ 120kHz
Linearity : ±1%
Accuracy : ±1.6%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 4µs
Current - Supply (Max) : 13.5mA
Operating Temperature : -40°C ~ 125°C
Polarization : Unidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Formed Leads, PFF
0
1551 in stock
Allegro MicroSystems, LLC.
Manufacturer : Allegro MicroSystems, LLC
Packaging : Tube
Series : Automotive, AEC-Q100
Part Status : Not For New Designs
For Measuring : AC/DC
Sensor Type : Hall Effect, Open Loop
Current - Sensing : 50A
Number of Channels : 1
Output : Ratiometric, Voltage
Sensitivity : 40mV/A
Frequency : DC ~ 120kHz
Linearity : ±1%
Accuracy : ±2%
Voltage - Supply : 3 V ~ 5.5 V
Response Time : 4µs
Current - Supply (Max) : 13.5mA
Operating Temperature : -40°C ~ 150°C
Polarization : Bidirectional
Mounting Type : Through Hole
Package / Case : 5-CB Formed Leads, PFF
0
27737 in stock
