VersaLogic Corporation
VersaLogic Corporation is the trusted name in embedded computer products. Featuring 5 to 10 year availability, -40 to +85° C operating temperature, Mil Standard 202G shock and vibration testing, and outstanding US-based support, VersaLogic products are ideal for critical applications that value ruggedness, reliability and long life.
Part Number
Manufacturer
Description
Unit Price
In Stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Liger
Part Status : Active
Core Processor : Intel Core i7-7600U
Speed : 3.9GHz
Number of Cores : 2
Power (Watts) : 13.3W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 16GB/16GB
Storage Interface : SATA, Mini PCIe, mSATA, microSD, SPI
Video Outputs : miniDP
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (4), USB 3.0 (2)
RS-232 (422, 485) : 4
Digital I/O Lines : 8
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : 0°C ~ 60°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Lynx
Part Status : Obsolete
Core Processor : AMD SC520
Speed : 133MHz
Number of Cores : 1
Power (Watts) : 4.70W
Cooling Type : Heat Sink
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 64MB/64MB
Storage Interface : CompactFlash
Video Outputs : -
Ethernet : 10/100 Mbps (1)
USB : -
RS-232 (422, 485) : 4
Digital I/O Lines : 0
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : 0°C ~ 60°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : -
Part Status : Active
Function : Ethernet
Power (Watts) : 2.6W
Cooling Type : -
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
Video Outputs : -
Ethernet : 10/100
USB : -
RS-232 (422, 485) : -
Digital I/O Lines : -
Analog Input:Output : -
Operating Temperature : -40°C ~ 85°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : -
Part Status : Active
Function : Ethernet
Power (Watts) : 2.6W
Cooling Type : -
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
Video Outputs : -
Ethernet : 10/100 (2)
USB : -
RS-232 (422, 485) : -
Digital I/O Lines : -
Analog Input:Output : -
Operating Temperature : -40°C ~ 85°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : -
Part Status : Active
Function : Ethernet
Power (Watts) : 2.6W
Cooling Type : -
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
Video Outputs : -
Ethernet : 10/100 (2)
USB : -
RS-232 (422, 485) : -
Digital I/O Lines : -
Analog Input:Output : -
Operating Temperature : -40°C ~ 85°C
0
28 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Bengal
Part Status : Active
Core Processor : Atom E3815
Speed : 1.46GHz
Number of Cores : 1
Power (Watts) : 6.75W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PCIe/104
RAM Capacity/Installed : 8GB/0GB
Storage Interface : SATA, mSATA
Video Outputs : VGA, Mini Display Port
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (5), USB 3.0 (1)
RS-232 (422, 485) : 2
Digital I/O Lines : 18
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
9 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Bengal
Part Status : Active
Core Processor : Atom E3826
Speed : 1.46GHz
Number of Cores : 2
Power (Watts) : 7.0W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PCIe/104
RAM Capacity/Installed : 8GB/0GB
Storage Interface : SATA, mSATA
Video Outputs : VGA, Mini Display Port
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (5), USB 3.0 (1)
RS-232 (422, 485) : 2
Digital I/O Lines : 18
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
16 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Bengal
Part Status : Active
Core Processor : Atom E3826
Speed : 1.46GHz
Number of Cores : 2
Power (Watts) : 7.0W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PCIe/104
RAM Capacity/Installed : 8GB/0GB
Storage Interface : SATA, mSATA
Video Outputs : VGA, Mini Display Port
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (5), USB 3.0 (1)
RS-232 (422, 485) : 2
Digital I/O Lines : 18
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
5 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Bengal
Part Status : Active
Core Processor : Atom E3845
Speed : 1.91GHz
Number of Cores : 4
Power (Watts) : 8.75W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PCIe/104
RAM Capacity/Installed : 8GB/0GB
Storage Interface : SATA, mSATA
Video Outputs : VGA, Mini Display Port
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (5), USB 3.0 (1)
RS-232 (422, 485) : 2
Digital I/O Lines : 18
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
26 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Lion
Part Status : Active
Core Processor : Intel Core i3
Speed : 2.4GHz
Number of Cores : 2
Power (Watts) : 12.0W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PCIe/104
RAM Capacity/Installed : 0GB/0GB
Storage Interface : SATA, mSATA, MicroSD
Video Outputs : Mini Display Port
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (4), USB 3.0 (2)
RS-232 (422, 485) : 4
Digital I/O Lines : 8
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
4 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Lion
Part Status : Active
Core Processor : Intel Core i3
Speed : 2.4GHz
Number of Cores : 2
Power (Watts) : 12.0W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PCIe/104
RAM Capacity/Installed : 4GB/4GB
Storage Interface : SATA, mSATA, MicroSD
Video Outputs : Mini Display Port
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (4), USB 3.0 (2)
RS-232 (422, 485) : 4
Digital I/O Lines : 8
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
11 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Lion
Part Status : Active
Core Processor : Intel Core i3
Speed : 2.4GHz
Number of Cores : 2
Power (Watts) : 12.0W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PCIe/104
RAM Capacity/Installed : 8GB/8GB
Storage Interface : SATA, mSATA, MicroSD
Video Outputs : Mini Display Port
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (4), USB 3.0 (2)
RS-232 (422, 485) : 4
Digital I/O Lines : 8
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
100 in stock
