Tamura Corporation of America
- Established in 1951, Microtran Corporation manufactured high-quality, magnetic components for both commercial and military applications. Offshore facilities provided expanded manufacturing capabilities on an extremely cost-effective basis for large volume requirements. Modified catalog items and custom designs were available on special order to meet customers' exact requirements.
Tamura Corporation of America acquired Microtran's product line and customer base in 1994. Prior to this acquisition, Tamura had been a subcontractor for Microtran for at least ten years and had manufactured many of the products found in the Microtran catalog. Since the acquisition, Tamura has combined identical and similar products into one product bearing a dual marking of both the Tamura and Microtran part numbers. This "dual marking" has enabled Tamura to continue to supply customers whose drawings referenced only the Microtran part number.
Part Number
Manufacturer
Description
Unit Price
In Stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Obsolete
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 10V, Series 20V
Current - Output (Max) : Parallel 1.2A, Series 600mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 12 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 63.50mm L x 50.80mm W
Height - Seated (Max) : 27.05mm
Voltage - Isolation : 1500Vrms
Weight : -
0
100 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Obsolete
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 115V, Series 230V
Current - Output (Max) : Parallel 100mA, Series 50mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 12 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 63.50mm L x 50.80mm W
Height - Seated (Max) : 27.05mm
Voltage - Isolation : 1500Vrms
Weight : -
0
100 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 12V, Series 24V
Current - Output (Max) : Parallel 200mA, Series 100mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.5 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 47.60mm L x 39.60mm W
Height - Seated (Max) : 16.80mm
Voltage - Isolation : 1500Vrms
Weight : -
0
454 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 12V, Series 24V
Current - Output (Max) : Parallel 500mA, Series 250mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 6 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 47.60mm L x 39.60mm W
Height - Seated (Max) : 21.60mm
Voltage - Isolation : 1500Vrms
Weight : -
0
2639 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 12V, Series 24V
Current - Output (Max) : Parallel 1A, Series 500mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 12 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 63.50mm L x 50.80mm W
Height - Seated (Max) : 27.05mm
Voltage - Isolation : 1500Vrms
Weight : -
0
25 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 15V, Series 30V
Current - Output (Max) : Parallel 400mA, Series 200mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 6 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 47.60mm L x 39.60mm W
Height - Seated (Max) : 21.60mm
Voltage - Isolation : 1500Vrms
Weight : -
0
724 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 17V, Series 34V
Current - Output (Max) : Parallel 800mA, Series 400mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 12 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 63.50mm L x 50.80mm W
Height - Seated (Max) : 27.05mm
Voltage - Isolation : 1500Vrms
Weight : -
0
71 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 15V, Series 30V
Current - Output (Max) : Parallel 170mA, Series 85mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.5 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 47.60mm L x 39.60mm W
Height - Seated (Max) : 16.80mm
Voltage - Isolation : 1500Vrms
Weight : -
0
71 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 17V, Series 34V
Current - Output (Max) : Parallel 340mA, Series 170mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 6 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 47.60mm L x 39.60mm W
Height - Seated (Max) : 21.60mm
Voltage - Isolation : 1500Vrms
Weight : -
0
100 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Obsolete
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 17V, Series 34V
Current - Output (Max) : Parallel 680mA, Series 340mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 12 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 63.50mm L x 50.80mm W
Height - Seated (Max) : 27.05mm
Voltage - Isolation : 1500Vrms
Weight : -
0
100 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 17V, Series 34V
Current - Output (Max) : Parallel 150mA, Series 75mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.5 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 47.60mm L x 39.60mm W
Height - Seated (Max) : 16.80mm
Voltage - Isolation : 1500Vrms
Weight : -
0
94 in stock
Tamura
Manufacturer : Tamura
Series : 3FL
Part Status : Obsolete
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 20V, Series 40V
Current - Output (Max) : Parallel 300mA, Series 150mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 6 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 47.60mm L x 39.60mm W
Height - Seated (Max) : 21.60mm
Voltage - Isolation : 1500Vrms
Weight : -
0
100 in stock
