Sumida
- Sumida is one of the leading manufacturers of coils and wire wound electronic products. Sumida currently has over 31000 products in its coil catalog-attesting to the diversity to which coil technology can be applied in the present day information age. All of Sumida's products are manufactured outside of Japan in various locations in the Asian region as well as in Mexico. This has allowed Sumida to keep costs to a minimum, spread risk and increase response times.
Sumida components can be found in audio visual equipment, CD-ROM drives, DVD/MD products, modems, networking hardware, liquid crystal display monitors, computer peripherals, air-conditioners, electronic automotive products such as Anti Lock Braking Systems, and a plethora of other electronic devices. See the product section of our site for more on our extensive range.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR54
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 15µH
Tolerance : ±20%
Current Rating : 1.3A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 140 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 25.9MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 2.52MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.228" L x 0.209" W (5.80mm x 5.30mm)
Height - Seated (Max) : 0.191" (4.85mm)
0
599 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR54
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 18µH
Tolerance : ±20%
Current Rating : 1.23A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 150 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 23.3MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 2.52MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.228" L x 0.209" W (5.80mm x 5.30mm)
Height - Seated (Max) : 0.191" (4.85mm)
0
30 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR54
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 22µH
Tolerance : ±20%
Current Rating : 1.11A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 180 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 19.5MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 2.52MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.228" L x 0.209" W (5.80mm x 5.30mm)
Height - Seated (Max) : 0.191" (4.85mm)
0
764 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR54
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 33µH
Tolerance : ±15%
Current Rating : 880mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 230 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 16.3MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 2.52MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.228" L x 0.209" W (5.80mm x 5.30mm)
Height - Seated (Max) : 0.191" (4.85mm)
0
2042 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR54
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 47µH
Tolerance : ±15%
Current Rating : 720mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 370 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 2.52MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.228" L x 0.209" W (5.80mm x 5.30mm)
Height - Seated (Max) : 0.191" (4.85mm)
0
901 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR54
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 5.6µH
Tolerance : ±20%
Current Rating : 2.48A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 49.4 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 7.96MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.228" L x 0.209" W (5.80mm x 5.30mm)
Height - Seated (Max) : 0.191" (4.85mm)
0
1336 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR54
Part Status : Discontinued at
Type : Wirewound
Material - Core : Ferrite
Inductance : 7.6µH
Tolerance : ±20%
Current Rating : 2.08A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 62.4 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 19.6MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 7.96MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.228" L x 0.209" W (5.80mm x 5.30mm)
Height - Seated (Max) : 0.191" (4.85mm)
0
1333 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR75
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 10µH
Tolerance : ±10%
Current Rating : 2.3A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 70 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 28MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 2.52MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max) : 0.217" (5.50mm)
0
1710 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR75
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 100µH
Tolerance : ±10%
Current Rating : 720mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 430 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 9.2MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max) : 0.217" (5.50mm)
0
727 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR75
Part Status : Discontinued at
Type : Wirewound
Material - Core : Ferrite
Inductance : 18µH
Tolerance : ±10%
Current Rating : 1.6A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 100 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 20MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 2.52MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max) : 0.217" (5.50mm)
0
184 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR75
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 22µH
Tolerance : ±10%
Current Rating : 1.5A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 110 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 17MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 2.52MHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max) : 0.217" (5.50mm)
0
318 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CR75
Part Status : Active
Type : Wirewound
Material - Core : Ferrite
Inductance : 220µH
Tolerance : ±10%
Current Rating : 490mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 960 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 5.2MHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max) : 0.217" (5.50mm)
0
9960 in stock
