Seoul Semiconductor
- Seoul Semiconductor manufacturers and packages a wide selection of light emitting diodes (LEDs) for the automotive, lighting, appliance, mobile, signage, and back lighting units (BLU) markets. The company is the world’s fifth largest LED supplier, holding more than 10, 000 patents globally, while offering a wide range of LED technology and production capacity in areas such as "nPola", deep UV LEDs, and "Acrich", the world’s first commercially produced AC LED.
Part Number
Manufacturer
Description
Unit Price
In Stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC40 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 5030 lm (Typ)
Current - Test : 1A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 136 lm/W
Current - Max : 1.28A
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
3 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC40 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 5030 lm (Typ)
Current - Test : 1A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 136 lm/W
Current - Max : 1.28A
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
292 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC6 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 750 lm (Typ)
Current - Test : 180mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 113 lm/W
Current - Max : 320mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 13.50mm L x 13.50mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
181 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC6 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 710 lm (Typ)
Current - Test : 180mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 107 lm/W
Current - Max : 320mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 13.50mm L x 13.50mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
88 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC12 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 1500 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 116 lm/W
Current - Max : 480mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC18 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 2150 lm (Typ)
Current - Test : 500mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 116 lm/W
Current - Max : 640mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
9 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC18 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 2050 lm (Typ)
Current - Test : 500mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 111 lm/W
Current - Max : 640mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
305 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC25 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 3400 lm (Typ)
Current - Test : 700mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 131 lm/W
Current - Max : 960mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
257 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC25 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 3140 lm (Typ)
Current - Test : 700mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 121 lm/W
Current - Max : 960mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
238 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC25 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 3000 lm (Typ)
Current - Test : 700mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 116 lm/W
Current - Max : 960mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
176 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC40 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 4650 lm (Typ)
Current - Test : 1A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 126 lm/W
Current - Max : 1.28A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
11 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC40 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 4300 lm (Typ)
Current - Test : 1A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 116 lm/W
Current - Max : 1.28A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
237 in stock
