Pulse Electronics Corporation
- Pulse Electronics is the electronic components partner that helps customers build the next great product by providing the needed technical solutions. Pulse has a long operating history of innovation in magnetics, antennas and connectors, as well as the ability to ramp quickly into high-quality, high-volume production. The Company serves the wireless and wireline communications, power management, military/aerospace and automotive industries. Previously, the holding and operating companies were known as Technitrol, Inc. and Pulse Engineering, respectively. Pulse is a participating member of IEEE, ATIS, ETSI, HDMI, the DSL Forum, CommNexus, and MoCA.
Part Number
Manufacturer
Description
Unit Price
In Stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Bulk
Series : -
Part Status : Active
Frequency Group : Wide Band
Frequency (Center/Band) : 5GHz
Frequency Range : 4.9GHz ~ 5.85GHz
Antenna Type : PCB Trace
Number of Bands : 1
VSWR : -
Return Loss : -
Gain : 2dBi
Power - Max : -
Features : -
Termination : Connector, IPEX (U.FL)
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : 0.031" (0.80mm)
Applications : -
0
1253 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : -
Series : Embedded PCB Ant
Part Status : Active
Frequency Group : UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz)
Frequency (Center/Band) : 2.45GHz, 5.425GHz
Frequency Range : 2.4GHz ~ 2.5GHz, 4.9GHz ~ 5.95GHz
Antenna Type : PCB Trace
Number of Bands : 2
VSWR : 2
Return Loss : -
Gain : 3dBi
Power - Max : 2W
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.063" (1.60mm)
Applications : General Purpose
0
270 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Embedded Antenna
Part Status : Active
Frequency Group : SHF (f > 4 GHz)
Frequency (Center/Band) : 5.45GHz
Frequency Range : 4.9GHz ~ 6GHz
Antenna Type : PCB Trace
Number of Bands : 1
VSWR : 2
Return Loss : -
Gain : 4.5dBi
Power - Max : 5W
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.094" (2.40mm)
Applications : General Purpose
0
3000 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Embedded Antenna
Part Status : Active
Frequency Group : SHF (f > 4 GHz)
Frequency (Center/Band) : 5.45GHz
Frequency Range : 4.9GHz ~ 6GHz
Antenna Type : PCB Trace
Number of Bands : 1
VSWR : 2
Return Loss : -
Gain : 4.5dBi
Power - Max : 5W
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.094" (2.40mm)
Applications : General Purpose
0
3000 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Embedded Antenna
Part Status : Active
Frequency Group : UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz)
Frequency (Center/Band) : 2.45GHz, 5.425GHz
Frequency Range : 2.4GHz ~ 2.5GHz, 4.9GHz ~ 6GHz
Antenna Type : PCB Trace
Number of Bands : 2
VSWR : 2
Return Loss : -
Gain : 3.7dBi, 5.5dBi
Power - Max : 5W
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.630" (16.00mm)
Applications : General Purpose
0
200 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : -
Series : Embedded PCB Ant
Part Status : Active
Frequency Group : UHF (2 GHz ~ 3 GHz)
Frequency (Center/Band) : 2.45GHz
Frequency Range : 2.4GHz ~ 2.5GHz
Antenna Type : PCB Trace
Number of Bands : 1
VSWR : 1.6
Return Loss : -
Gain : 3dBi
Power - Max : 2W
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.063" (1.60mm)
Applications : General Purpose
0
265 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Domino
Part Status : Active
Frequency Group : Wide Band
Frequency (Center/Band) : 829MHz, 1.575GHz, 1.9GHz, 2.5GHz
Frequency Range : 698MHz ~ 960MHz, 1.43GHz ~ 1.66GHz, 1.69GHz ~ 2.2GHz, 2.3GHz ~ 2.7GHz
Antenna Type : Flat Bar
Number of Bands : 4
VSWR : 3
Return Loss : -6dB
Gain : 1.5dBi, 2dBi, 5.5dBi, 5dBi
Power - Max : 5W
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.118" (3.00mm)
Applications : GPS, LTE
0
3346 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Bulk
Series : GEMINI
Part Status : Active
Frequency Group : Wide Band
Frequency (Center/Band) : 2.15GHz
Frequency Range : 698MHz ~ 3.6GHz
Antenna Type : Flat Patch
Number of Bands : 1
VSWR : -
Return Loss : -10dB
Gain : 4dBi
Power - Max : 3W
Features : -
Termination : Cable (100mm) - U.FL
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : -
Applications : LTE
0
2712 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Bulk
Series : GEMINI
Part Status : Active
Frequency Group : Wide Band
Frequency (Center/Band) : 2.15GHz
Frequency Range : 698MHz ~ 3.6GHz
Antenna Type : Flat Patch
Number of Bands : 1
VSWR : -
Return Loss : -7.5dB
Gain : 4.2dBi
Power - Max : 3W
Features : -
Termination : Cable (100mm) - U.FL
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : -
Applications : LTE
0
4724 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Bulk
Series : GEMINI
Part Status : Active
Frequency Group : UHF (1 GHz ~ 2 GHz)
Frequency (Center/Band) : 1.585GHz
Frequency Range : 1.56GHz ~ 1.61GHz
Antenna Type : Flat Patch
Number of Bands : 1
VSWR : -
Return Loss : -10dB
Gain : 0.3dBi
Power - Max : 3W
Features : -
Termination : Cable (100mm) - U.FL
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : -
Applications : Beidou, Galileo, GLONASS, GPS
0
5331 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Bulk
Series : -
Part Status : Active
Frequency Group : Wide Band
Frequency (Center/Band) : 920MHz, 1.59GHz, 1.94GHz
Frequency Range : 880MHz ~ 960MHz, 1.575GHz ~ 1.605GHz, 1.71GHz ~ 2.17GHz
Antenna Type : Flat Patch
Number of Bands : 3
VSWR : -
Return Loss : 8dB
Gain : 2dBi
Power - Max : -
Features : -
Termination : Cable (100mm) - U.FL
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : 0.008" (0.20mm)
Applications : GNSS
0
777 in stock
Pulse Electronics Corporation
Manufacturer : PulseLarsen Antennas
Packaging : Bulk
Series : -
Part Status : Active
Frequency Group : Wide Band
Frequency (Center/Band) : 2.4GHz, 5.4GHz
Frequency Range : 2.4GHz ~ 2.5GHz, 4.9GHz ~ 5.925GHz
Antenna Type : Flat Patch
Number of Bands : 2
VSWR : 2
Return Loss : -
Gain : 4dBi
Power - Max : 2W
Features : -
Termination : Cable (100mm) - U.FL
Ingress Protection : -
Mounting Type : Adhesive
Height (Max) : 0.006" (0.15mm)
Applications : Bluetooth, Wi-Fi, Zigbee™
0
502 in stock
