Everlight Electronics
- Everlight Electronics Co., Ltd. was founded in 1983 in Taipei, Taiwan. Playing a critical role in the formation of the global LED industry, the company is rapidly ascending to become a leading supplier due to its dedication to certification, R&D, production, quality, marketing and global customer service. Everlight provides a diverse product portfolio consisting of High Power LEDs, Lamps, SMD LEDs, LED Lighting Modules, Digital Displays, Optocouplers and Infrared Components for various applications. Today, Everlight is a global company with over 6,400 employees based in China, Hong Kong, Japan, Korea, Singapore, Malaysia, Germany, Sweden, U.S., and Canada.
Part Number
Manufacturer
Description
Unit Price
In Stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : Orange
Wavelength : 615nm (610nm ~ 620nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.35V
Lumens/Watt @ Current - Test : 68 lm/W
Current - Max : 600mA
Flux @ Current/Temperature - Test : 56 lm (52 lm ~ 60 lm)
Temperature - Test : 25°C
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1218 (3246 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.120" L x 0.177" W (3.05mm x 4.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : Red
Wavelength : 625nm (620nm ~ 630nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.35V
Lumens/Watt @ Current - Test : 68 lm/W
Current - Max : 600mA
Flux @ Current/Temperature - Test : 56 lm (52 lm ~ 60 lm)
Temperature - Test : 25°C
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1218 (3246 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.120" L x 0.177" W (3.05mm x 4.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 2700K (2580K ~ 2870K)
Flux @ 85°C, Current - Test : 53 lm
Flux @ 25°C, Current - Test : 60 lm (60 lm ~ 70 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 53 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 600mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1812 (4532 Metric)
Supplier Device Package : -
Size / Dimension : 0.177" L x 0.120" W (4.50mm x 3.05mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : Orange
Wavelength : 615nm (610nm ~ 620nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.35V
Lumens/Watt @ Current - Test : 79 lm/W
Current - Max : 600mA
Flux @ Current/Temperature - Test : 65 lm (60 lm ~ 70 lm)
Temperature - Test : 25°C
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1218 (3246 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.120" L x 0.177" W (3.05mm x 4.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Tape & Reel (TR)
Series : SHUEN
Part Status : Discontinued at
Color : Red
Wavelength : 625nm (620nm ~ 630nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.35V
Lumens/Watt @ Current - Test : 79 lm/W
Current - Max : 600mA
Flux @ Current/Temperature - Test : 65 lm (60 lm ~ 70 lm)
Temperature - Test : 25°C
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1218 (3246 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.120" L x 0.177" W (3.05mm x 4.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : Green
Wavelength : 525nm (520nm ~ 530nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 66 lm/W
Current - Max : 600mA
Flux @ Current/Temperature - Test : 75 lm (70 lm ~ 80 lm)
Temperature - Test : 25°C
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1218 (3246 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.120" L x 0.177" W (3.05mm x 4.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : Green
Wavelength : 530nm (525nm ~ 535nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 66 lm/W
Current - Max : 600mA
Flux @ Current/Temperature - Test : 75 lm (70 lm ~ 80 lm)
Temperature - Test : 25°C
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1218 (3246 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.120" L x 0.177" W (3.05mm x 4.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
1 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 2700K (2580K ~ 2870K)
Flux @ 85°C, Current - Test : 61 lm
Flux @ 25°C, Current - Test : 70 lm (70 lm ~ 80 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.4V
Lumens/Watt @ Current - Test : 59 lm/W
CRI (Color Rendering Index) : 75
Current - Max : 400mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1812 (4532 Metric)
Supplier Device Package : -
Size / Dimension : 0.177" L x 0.120" W (4.50mm x 3.05mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3000K (2870K ~ 3220K)
Flux @ 85°C, Current - Test : 61 lm
Flux @ 25°C, Current - Test : 70 lm (70 lm ~ 80 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.4V
Lumens/Watt @ Current - Test : 59 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 400mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1812 (4532 Metric)
Supplier Device Package : -
Size / Dimension : 0.177" L x 0.120" W (4.50mm x 3.05mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3500K (3220K ~ 3710K)
Flux @ 85°C, Current - Test : 61 lm
Flux @ 25°C, Current - Test : 70 lm (70 lm ~ 80 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.4V
Lumens/Watt @ Current - Test : 59 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 400mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1812 (4532 Metric)
Supplier Device Package : -
Size / Dimension : 0.177" L x 0.120" W (4.50mm x 3.05mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Tape & Reel (TR)
Series : SHUEN
Part Status : Obsolete
Color : Green
Wavelength : 525nm (520nm ~ 530nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 75 lm/W
Current - Max : 400mA
Flux @ Current/Temperature - Test : 85 lm (80 lm ~ 90 lm)
Temperature - Test : 25°C
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1218 (3246 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.120" L x 0.177" W (3.05mm x 4.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Everlight Electronics
Manufacturer : Everlight Electronics Co Ltd
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SHUEN
Part Status : Discontinued at
Color : Green
Wavelength : 530nm (525nm ~ 535nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 75 lm/W
Current - Max : 400mA
Flux @ Current/Temperature - Test : 85 lm (80 lm ~ 90 lm)
Temperature - Test : 25°C
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1218 (3246 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.120" L x 0.177" W (3.05mm x 4.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
